蓖麻有效穗数QTL定位及候选基因鉴定

doi:10.7668/hbnxb.20194396

摘要/Abstract

摘要：

有效穗数是蓖麻产量的重要构成因子。为揭示蓖麻有效穗数的遗传基础及挖掘其候选基因,利用表型差异显著的2个亲本杂交构建F₂和BC₁(F₁×P₂)群体,通过SSR引物基因分型以及CIM和ICIM-ADD 2种检测方法对单株有效穗数和一级分枝有效穗数进行QTL定位,并以相同方法在S₁群体进一步验证QTL重复性。在F₂群体中共检测到9/5(CIM/ICIM-ADD,下同)个QTL,其中,单株有效穗数和一级分枝有效穗数QTL分别为3/2,6/3个,分别解释了6.70%/11.87%和25.15%/13.87%的表型变异。BC₁群体的定位结果与F₂群体基本一致。其中,qESNPP3.1 和qEPBSN3.1为稳定QTL,贡献率都接近10%,后者在S₁群体中再次检测到,贡献率为13.27%;它们在RCM915~RCM950标记区间内重叠分布,共同构成1个调控蓖麻有效穗数的主效QTL簇。从RCM915~RCM950标记区间中共鉴定了2个蓖麻有效穗数候选基因(即Rc-US03g04880和Rc-US03g05950),它们在双亲多个分枝组织中差异表达。上述结果为蓖麻有效穗数的标记辅助选择提供了重要的分子标记,也为其遗传和生理机理研究提供了必要的候选基因。

关键词: 蓖麻, 有效穗数, QTL定位, 候选基因, 主效QTL

Abstract:

Effective spike number is an important component of castor yield.In order to reveal the genetic basis and mining candidate genes of effective spike number,the QTLs conferring effective spike number per plant(ESNPP)and number of effective primary branch spike(EPBSN)were mapped by genotyping with SSR primers and by the 2 detection methods(CIM and ICIM-ADD)in the populations F₂ and BC₁ (F₁×P₂)derived from 2 parents with significant phenotypic differences,and QTL remapping was conducted in S₁ population by the same method.A total of 9/5(CIM/ICIM-ADD,the same below) QTLs were identified in the F₂ population,including 3/2 and 6/3 underlying ESNPP and EPBSN,with a phenotypic variation explained(PVE)of 6.70%/11.87% and 25.15%/13.87%,respectively.The mapping results in BC₁ population were generally consistent with those in F₂ population.Among them, qESNPP3.1 and qEPBSN3.1 were stable QTLs with contribution rates close to 10%,and the latter was detected again in S₁ population with a PVE of 13.27%;the stable QTLs were overlappingly located in the marker interval RCM915—RCM950,and together constituted a main-effect QTL cluster underlying the effective spike number.Two candidate genes,Rc-US03g04880 and Rc-US03g05950,were annotated from the marker interval,which were differentially expressed in multiple branching tissues of both parents.The above results provided essential molecular markers for marker-assisted selection of the effective spike number and necessary candidate genes for its genetic and physiologic mechanism study in castor.

Key words: Castor, Effective spike number, QTL mapping, Candidate gene, Main-effect QTL

黄冠荣, 殷学贵, 陆建农, 张柳琴, 刘朝裕, 张肖肖, 林海虹, 左金鹰. 蓖麻有效穗数QTL定位及候选基因鉴定[J]. 华北农学报, 2023, 38(6): 36-44. doi: 10.7668/hbnxb.20194396.

HUANG Guanrong, YIN Xuegui, LU Jiannong, ZHANG Liuqin, LIU Chaoyu, ZHANG Xiaoxiao, LIN Haihong, ZUO Jinying. QTL Mapping and Candidate Gene Identification of Effective Spike Number in Ricinus communis L.[J]. Acta Agriculturae Boreali-Sinica, 2023, 38(6): 36-44. doi: 10.7668/hbnxb.20194396.

http://www.hbnxb.net/CN/Y2023/V38/I6/36

图/表 8

参考文献 47

[1]	Ogunniyi D S. Castor oil:a vital industrial raw material[J]. Bioresource Technolog, 2006, 97(9):1086-1091.doi:10.1016/j.biortech.2005.03.028.
[2]	Carrino L, Visconti D, Fiorentino N, Fagnano M. Biofuel production with castor bean:a win-win strategy for marginal land[J]. Agronom, 2020, 10(11):1690.doi:10.3390/agronomy10111690. URL
[3]	Osorio-González C S, Gómez-Falcon N, Sandoval-Salas F, Saini R, Brar S K, Ramírez A A. Production of biodiesel from castor oil:a review[J]. Energies, 2020, 13(10):2467.doi:10.3390/en13102467. URL
[4]	Wang B, Smith S M, Li J Y. Genetic regulation of shoot architecture[J]. Annual Review of Plant Biolog, 2018, 69(1):437-468.doi:10.1146/annurev-arplant-042817-040422.
[5]	McSteen P, Leyser O. Shoot branching[J]. Annual Review of Plant Biolog, 2005, 56:353-374.doi:10.1146/annurev.arplant.56.032604.144122.
[6]	Shaaf S, Bretani G, Biswas A, Fontana I M, Rossini L. Genetics of barley tiller and leaf development[J]. Journal of Integrative Plant Biolog, 2019, 61(3):226-256.doi:10.1111/jipb.12757.
[7]	Li X Y, Qian Q, Fu Z M, Wang Y H, Xiong G S, Zeng D L, Wang X Q, Liu X F, Teng S, Hiroshi F, Yuan M, Luo D, Han B, Li J Y. Control of tillering in rice[J]. Nature, 2003, 422(6932):618-621.doi:10.1038/nature01518.
[8]	Zhang B, Liu X, Xu W N, Chang J Z, Li A, Mao X G, Zhang X Y, Jing R L. Novel function of a putative MOC1 ortholog associated with spikelet number per spike in common wheat[J]. Scientific Reports, 2015, 5:12211.doi:10.1038/srep12211. pmid: 26197925
[9]	Takeda T, Suwa Y, Suzuki M, Kitano H, Ueguchi-Tanaka M, Ashikari M, Matsuoka M, Ueguchi C. The OsTB1 gene negatively regulates lateral branching in rice[J]. The Plant Journal, 2003, 33(3):513-520.doi:10.1046/j.1365-313x.2003.01648.x. URL
[10]	Diao Y Y, Zhan J J, Zhao Y Y, Liu L S, Liu P P, Wei X, Ding Y P, Sajjad M, Hu W, Wang P, Ge X Y. GhTIE1 regulates branching through modulating the transcriptional activity of TCPs in cotton and Arabidopsis[J]. Front iers in Plant Science, 2019, 10:1348.doi:10.3389/fpls.2019.01348.
[11]	Zhan J J, Chu Y, Wang Y, Diao Y Y, Zhao Y Y, Liu L S, Wei X, Meng Y, Li F G, Ge X Y. The miR164-GhCUC2-GhBRC1 module regulates plant architecture through abscisic acid in cotton[J]. Plant Biotechnology Journal, 2021, 19(9):1839-1851.doi:10.1111/pbi.13599. pmid: 33960609
[12]	Oikawa T, Kyozuka J. Two-step regulation of LAX PANICLE1 protein accumulation in axillary meristem formation in rice[J]. The Plant Cell, 2009, 21(4):1095-1108.doi:10.1105/tpc.108.065425. URL
[13]	Zhang Z Y, Li J J, Yao G X, Zhang H L, Dou H J, Shi H L, Sun X M, Li Z C. Fine mapping and cloning of the grain number per-panicle gene(Gnp4)on chromosome 4 in rice(Oryza sativa L.)[J]. Agricultural Sciences in China, 2011, 10(12):1825-1833.doi:10.1016/S1671-2927(11)60182-X. URL
[14]	Tabuchi H, Zhang Y, Hattori S, Omae M, Shimizu-Sato S, Oikawa T, Qian Q, Nishimura M, Kitano H, Xie H, Fang X H, Yoshida H, Kyozuka J, Chen F, Sato Y. LAX PANICLE2 of rice encodes a novel nuclear protein and regulates the formation of axillary meristems[J]. The Plant Cell, 2011, 23(9):3276-3287.doi:10.1105/tpc.111.088765. pmid: 21963665
[15]	Miura K, Ikeda M, Matsubara A, Song X J, Ito M, Asano K, Matsuoka M, Kitano H, Ashikari M. OsSPL14 promotes panicle branching and higher grain productivity in rice[J]. Nature Genetics, 2010, 42(6):545-549.doi:10.1038/ng.592.
[16]	Jiao Y Q, Wang Y H, Xue D W, Wang J, Yan M X, Liu G F, Dong G J, Zeng D L, Lu Z F, Zhu X D, Qian Q, Li J Y. Regulation of OsSPL14 by OsmiR156 defines ideal plant architecture in rice[J]. Nature Genetics, 2010, 42(6):541-544.doi:10.1038/ng.591.
[17]	Zhang Q, Xie J Y, Zhu X Y, Ma X Q, Yang T, Khan N U, Zhang S Y, Liu M S, Li L, Liang Y T, Pan Y H, Li D T, Li J J, Li Z C, Zhang H L, Zhang Z Y. Natural variation in Tiller Number 1 affects its interaction with TIF1 to regulate tillering in rice[J]. Plant Biotechnology Journal, 2023, 21(5):1044-1057.doi:10.1111/pbi.14017. URL
[18]	Dong C H, Zhang L C, Zhang Q, Yang Y X, Li D P, Xie Z C, Cui G Q, Chen Y Y, Wu L F, Li Z, Liu G X, Zhang X Y, Liu C M, Chu J F, Zhao G Y, Xia C, Jia J Z, Sun J Q, Kong X Y, Liu X. Tiller Number1 encodes an ankyrin repeat protein that controls tillering in bread wheat[J]. Nature Communications, 2023, 14(1):836.doi:10.1038/s41467-023-36271-z. pmid: 36788238
[19]	Liang Q J, Chen L Y, Yang X, Yang H, Liu S L, Kou K, Fan L, Zhang Z F, Duan Z B, Yuan Y Q, Liang S, Liu Y C, Lu X T, Zhou G A, Zhang M, Kong F J, Tian Z X. Natural variation of Dt2 determines branching in soybean[J]. Nature Communications, 2022, 13(1):6429.doi:10.1038/s41467-022-34153-4.
[20]	Sun Z X, Su C, Yun J X, Jiang Q, Wang L X, Wang Y N, Cao D, Zhao F, Zhao Q S, Zhang M C, Zhou B, Zhang L, Kong F J, Liu B H, Tong Y P, Li X. Genetic improvement of the shoot architecture and yield in soya bean plants via the manipulation of GmmiR156b[J]. Plant Biotechnology Journal, 2019, 17(1):50-62.doi:10.1111/pbi.12946. URL
[21]	Luo J, Hang J N, Wu B L, Wei X L, Zhao Q Z, Fang Z M. Co-overexpression of genes for nitrogen transport,assimilation,and utilization boosts rice grain yield and nitrogen use efficiency[J]. The Crop Journal, 2023, 11(3):785-799.doi:10.1016/j.cj.2023.01.005. URL
[22]	Kanti M, Anjani K, Usha Kiran B, Vivekananda K. Agro-morphological and molecular diversity in castor(Ricinus communis L.) germplasm collected from Andaman and Nicobar Islands,India[J]. Czech Journal of Genetics and Plant Breeding, 2015, 51(3):96-109.doi:10.17221/205/2014-CJGPB. URL
[23]	Atinafu D M, Alayachew S A, Jida Z. Path coefficient analysis of some prominent agronomic traits in castor(Ricinus communis L.) germplasm[J]. Journal of Experimental Agriculture International, 2019, 41(3):1-12.doi:10.9734/jeai/2019/v41i330401.
[24]	顾帅磊, 陆建农, 黄家祥, 杨婷, 何晓琳, 李东娜, Akwasi Yeboah, 殷学贵. 蓖麻杂交组合收获指数评价[J]. 中国油料作物学报, 2022, 44(4):860-868.doi:10.19802/j.issn.1007-9084.2021153.
	Gu S L, Lu J N, Huang J X, Yang T, He X L, Li D N, Yeboah A, Yin X G. Evaluation of harvest index in castor hybrids combinations[J]. Chinese Journal of Oil Crop Sciences, 2022, 44(4):860-868.
[25]	Aher A R, Patel J A, Patel M P, Patel K V. Genetic analysis of seed yield and component characters over environments in castor(Ricinus communis L.)[J]. Electronic Journal of Plant Breeding, 2015, 6(1):141-149.doi:10.5958/0975-928X.2017.00011.4.
[26]	Pardshi P P, Sakhare S B, Ingle K P, Khelurkar V C. Genetic architecture studies of yield and its components in castor[J]. Electronic Journal of Plant Breeding, 2018, 9(3):790-796.doi:10.5958/0975-928X.2018.00098.4. URL
[27]	唐艳梅, 刘曙光. 蓖麻主要农艺性状配合力分析[J]. 内蒙古民族大学学报(自然科学版), 2013, 28(5):540-545.doi:10.3969/j.issn.1671-0185.2013.05.013.
	Tang Y M, Liu S G. Analysis on combining ability of Castor main agronomic characters[J]. Journal of Inner Mongolia University for Nationalities (Natural Sciences), 2013, 28(5):540-545.
[28]	严兴初. 蓖麻种质资源描述规范和数据标准[M]. 北京: 中国农业出版社, 2007.
	Yan X C. Castor bean germplasm resource description specifi-cation and standard data[M]. Beijing: China Agriculture Press, 2007.
[29]	Cullings K W. Design and testing of a plant-specific PCR primer for ecological and evolutionary studies[J]. Molecular Ecolog, 1992, 1(4):233-240.doi:10.1111/j.1365-294x.1992.tb00182.x. URL
[30]	Yeboah A, Lu J N, Ting Y, Karikari B, Gu S L, Xie Y, Liu H Y, Yin X G. Genome-wide association study identifies loci,beneficial alleles,and candidate genes for cadmium tolerance in castor(Ricinus communis L.)[J]. Industrial Crops and Products, 2021, 171:113842.doi:10.1016/j.indcrop.2021.113842. URL
[31]	Liu S, Yin X G, Lu J N, Liu C, Bi C, Zhu H B, Shi Y Z, Zhang D, Wen D Y, Zheng J, Cui Y, Li W J. The first genetic linkage map of Ricinus communis L.based on genome-SSR markers[J]. Industrial Crops and Products, 2016, 89:103-108.doi:10.1016/j.indcrop.2016.04.063. URL
[32]	Chan A P, Crabtree J, Zhao Q, Lorenzi H, Orvis J, Puiu D, Melake-Berhan A, Jones K M, Redman J, Chen G, Cahoon E B, Gedil M, Stanke M, Haas B J, Wortman J R, Fraser-Liggett C M, Ravel J, Rabinowicz P D. Draft genome sequence of the oilseed species Ricinus communis[J]. Nature Biotechnolog, 2010, 28(9):951-956.doi:10.1038/nbt.1674.
[33]	Yadav P, Saxena K B, Hingane A, Kumar C V S, Kandalkar V S, Varshney R K, Saxena R K. An "Axiom Cajanus SNP Array" based high density genetic map and QTL mapping for high-selfing flower and seed quality traits in pigeonpea[J]. BMC Genomics, 2019, 20(1):235.doi:10.1186/s12864-019-5595-3.
[34]	Wu J, Mao L L, Tao J C, Wang X X, Zhang H J, Xin M, Shang Y Q, Zhang Y N, Zhang G H, Zhao Z T, Wang Y M, Cui M S, Wei L M, Song X L, Sun X Z. Dynamic quantitative trait loci mapping for plant height in recombinant inbred line population of upland cotton[J]. Frontiers in Plant Science, 2022, 13:914140.doi:10.3389/fpls.2022.914140. URL
[35]	Wang H, Jia J, Cai Z D, Duan M M, Jiang Z, Xia Q J, Ma Q B, Lian T X, Nian H. Identification of quantitative trait loci(QTLs)and candidate genes of seed iron and zinc content in soybean [Glycine max (L.) Merr.][J]. BMC Genomics, 2022, 23(1):146.doi:10.1186/s12864-022-08313-1.
[36]	McCouch S R, Chen X L, Panaud O, Temnykh S, Xu Y B, Cho Y G, Huang N, Ishii T, Blair M. Microsatellite marker development,mapping and applications in rice genetics and breeding[M]// Oryza:from molecule to plant. Dordrecht: Springer Nether Lands, 1997:89-99.doi:10.1007/978-94-011-5794-0_9.
[37]	Livak K J, Schmittgen T D. Analysis of relative gene expression data using real-time quantitative PCR and the 2^-ΔΔCT method[J]. Methods, 2001, 25(4):402-408.doi:10.1006/meth.2001.1262. pmid: 11846609
[38]	盖钧镒. 植物数量性状遗传体系[M]. 北京: 科学出版社, 2003.
	Gai J Y. Genetic system of quantitative traits in plants[M]. Beijing: Science Press, 2003.
[39]	Srivastava R, Upadhyaya H D, Kumar R, Daware A, Basu U, Shimray P W, Tripathi S, Bharadwaj C, Tyagi A K, Parida S K. A multiple QTL-seq strategy delineates potential genomic loci governing flowering time in chickpea[J]. Frontiers in Plant Science, 2017, 8:1105.doi:10.3389/fpls.2017.01105. pmid: 28751895
[40]	Yang X H, Xia X Z, Zhang Z Q, Nong B X, Zeng Y, Wu Y Y, Xiong F Q, Zhang Y X, Liang H F, Pan Y H, Dai G X, Deng G F, Li D T. Identification of anthocyanin biosynthesis genes in rice pericarp using PCAMP[J]. Plant Biotechnology Journal, 2019, 17(9):1700-1702.doi:10.1111/pbi.13133. pmid: 31004548
[41]	Uchida N, Igari K, Bogenschutz N L, Torii K U, Tasaka M. Arabidopsis ERECTA-family receptor kinases mediate morphological alterations stimulated by activation of NB-LRR-type UNI proteins[J]. Plant and Cell Physiolog, 2011, 52(5):804-814.doi:10.1093/pcp/pcr032.
[42]	Schwechheimer C, Serino G, Deng X W. Multiple ubiquitin ligase-mediated processes require COP9 signalosome and AXR1 function[J]. The Plant Cell, 2002, 14(10):2553-2563.doi:10.1105/tpc.003434. URL
[43]	Rivarola M, Foster J T, Chan A P, Williams A L, Rice D W, Liu X Y, Melake-Berhan A, Huot Creasy H H, Puiu D, Rosovitz M J, Khouri H M, Beckstrom-Sternberg S M, Allan G J, Keim P, Ravel J, Rabinowicz P D. Castor bean organelle genome sequencing and worldwide genetic diversity analysis[J]. PLoS One, 2011, 6(7):e21743.doi:10.1371/journal.pone.0021743. URL
[44]	Li H, Hearne S, Bänziger M, Li Z, Wang J. Statistical properties of QTL linkage mapping in biparental genetic populations[J]. Heredit, 2010, 105(3):257-267.doi:10.1038/hdy.2010.56.
[45]	贾晓昀, 朱继杰, 赵红霞, 王士杰, 李妙, 王国印. 棉花产量相关性状QTL定位及候选基因筛选[J]. 华北农学报, 2021, 36(2):54-61.doi:10.7668/hbnxb.20192084.
	Jia X Y, Zhu J J, Zhao H X, Wang S J, Li M, Wang G Y. QTL analysis and candidate gene annotation for cotton yield related traits[J]. Acta Agriculturae Boreali-Sinica, 2021, 36(2):54-61. doi: 10.7668/hbnxb.20192084
[46]	Li Z Q, Xu Y H. Bulk segregation analysis in the NGS era:a review of its teenage years[J]. The Plant Journal, 2022, 109(6):1355-1374.doi:10.1111/tpj.15646. URL
[47]	Parida S K, Srivastava R, Bajaj D. A genome-wide mQTL-seq scan identifies potential molecular signatures regulating plant height in chickpea[J]. Plant Molecular Biology Reporter, 2017, 35(2):273-286.doi:10.1007/s11105-016-1021-z. URL

性状 Trait	世代 Generation	群体规模 Population size	极差 Range	均值±标准差 Mean±s	变异系数/% CV	偏度 Skewness	峰度 Kurtosis
单株有效穗数	P₁	25	3~4	3.64±0.50A	13.87	-0.66	-1.96
Effective spike	P₂	25	5~6	5.36±0.50B	9.28	0.67	-1.84
number per plant	F₁	25	7~11	9.08±1.24	13.65	0.16	-0.61
	F₂	282	1~20	6.38±2.87	45.06	0.76	1.15
	BC₁	250	1~18	8.95±3.36	37.52	-0.02	-0.30
一级分枝有效穗数	P₁	25	2~3	2.64±0.50A	19.14	-0.66	-1.96
Number of effective	P₂	25	3~4	3.36±0.50B	14.81	0.67	-1.84
primary branch spike	F₁	25	3~5	3.67±0.78	21.23	0.72	-0.79
	F₂	282	1~10	4.11±1.62	39.47	0.81	0.53
	BC₁	250	1~10	4.94±1.61	32.47	0.19	0.15

性状 Trait	世代 Generation	群体规模 Population size	极差 Range	均值±标准差 Mean±s	变异系数/% CV	偏度 Skewness	峰度 Kurtosis
单株有效穗数	P₁	25	3~4	3.64±0.50A	13.87	-0.66	-1.96
Effective spike	P₂	25	5~6	5.36±0.50B	9.28	0.67	-1.84
number per plant	F₁	25	7~11	9.08±1.24	13.65	0.16	-0.61
	F₂	282	1~20	6.38±2.87	45.06	0.76	1.15
	BC₁	250	1~18	8.95±3.36	37.52	-0.02	-0.30
一级分枝有效穗数	P₁	25	2~3	2.64±0.50A	19.14	-0.66	-1.96
Number of effective	P₂	25	3~4	3.36±0.50B	14.81	0.67	-1.84
primary branch spike	F₁	25	3~5	3.67±0.78	21.23	0.72	-0.79
	F₂	282	1~10	4.11±1.62	39.47	0.81	0.53
	BC₁	250	1~10	4.94±1.61	32.47	0.19	0.15

群体 Pop	方法 Method	性状 Trait	QTL	染色体 Chr	连锁群 LG	位置 Pos	LOD	加性 Add	显性 Dom	贡献率/% PVE	置信区间 CI		标记区间 MI
F₂	CIM	ESNPP	FqESNPP6.1	6	7	4.01	2.70	-0.48	-1.21	0.09	0~	12.7	RCM1556~	RCM1521
			FqESNPP1.1	1	8	8.01	2.01	-0.16	-1.12	0.44	0~	14.0	RCM150~	RCM1824
			qESNPP3.1	3	10	20.81	5.29	-1.15	-0.32	6.17	15.7~	30.0	RCM915~	RCM950
		EPBSN	FqEPBSN9.1	9	1	7.01	2.98	-0.73	-0.53	2.55	0.9~	16.8	RCM1335~	RCM1336
			FqEPBSN10.1	10	4	25.61	2.16	-0.76	0.09	5.87	14.2~	27.7	RCM938~	RCM279
			FqEPBSN6.3	6	5	11.01	3.52	0.75	-0.01	5.49	2.9~	16.7	RCM562~	RCM98
			FqEPBSN6.2	6	5	27.51	2.47	-0.61	-0.20	1.73	27.2~	41.1	RCM98~	RCM581
			FqEPBSN6.1	6	7	7.01	2.21	-0.35	-0.56	0.13	0~	21.2	RCM1556~	RCM1523
			qEPBSN3.1	3	10	23.11	4.55	-0.64	0.16	9.38	17.8~	30.7	RCM915~	RCM950
	ICIM-	ESNPP	FqESNPP6.1	6	7	4.00	2.90	-0.55	-1.20	4.93	0~	12.5	RCM1556~	RCM1521
	ADD		qESNPP3.1	3	10	23.00	4.61	-1.14	-0.33	6.94	16.5~	31.5	RCM917~	RCM950
		EPBSN	FqEPBSN9.2	9	1	18.00	2.16	-0.33	-0.39	3.16	16.5~	18.0	RCM1336~	RCM1338
			FqEPBSN6.1	6	7	7.00	2.46	-0.40	-0.58	5.29	0~	17.5	RCM1556~	RCM1521
			qEPBSN3.1	3	10	23.00	3.25	-0.56	0.11	5.42	17.5~	33.5	RCM917~	RCM950
BC₁	CIM	ESNPP	BqESNPP7.1	7	1	1.00	5.01	2.12	-	3.52	0.4~	13.3	RCM1778~	RCM1772
			qESNPP3.1	3	4	4.00	18.81	3.61	-	6.27	12.3~	26.3	RCM950~	RCM931
		EPBSN	BqEPBSN7.1	7	1	1.00	5.01	2.31	-	4.42	2.6~	6.0	RCM1778~	RCM1625
			qEPBSN3.1	3	4	4.00	18.81	3.18	-	5.62	13.5~	26.8	RCM950~	RCM931
	ICIM-	ESNPP	qESNPP3.1	3	4	19.00	4.45	-1.96	-	7.92	12.5~	21.5	RCM920~	RCM917
	ADD	EPBSN	qEPBSN3.1	3	4	21.00	3.95	-0.87	-	7.21	17.5~	27.5	RCM920~	RCM917
S₁	CIM	EPBSN	qEPBSN3.1	3	1	15.01	2.18	-0.47	0.23	13.27	1.5~	23.5	RCM915~	RCM950

群体 Pop	方法 Method	性状 Trait	QTL	染色体 Chr	连锁群 LG	位置 Pos	LOD	加性 Add	显性 Dom	贡献率/% PVE	置信区间 CI		标记区间 MI
F₂	CIM	ESNPP	FqESNPP6.1	6	7	4.01	2.70	-0.48	-1.21	0.09	0~	12.7	RCM1556~	RCM1521
			FqESNPP1.1	1	8	8.01	2.01	-0.16	-1.12	0.44	0~	14.0	RCM150~	RCM1824
			qESNPP3.1	3	10	20.81	5.29	-1.15	-0.32	6.17	15.7~	30.0	RCM915~	RCM950
		EPBSN	FqEPBSN9.1	9	1	7.01	2.98	-0.73	-0.53	2.55	0.9~	16.8	RCM1335~	RCM1336
			FqEPBSN10.1	10	4	25.61	2.16	-0.76	0.09	5.87	14.2~	27.7	RCM938~	RCM279
			FqEPBSN6.3	6	5	11.01	3.52	0.75	-0.01	5.49	2.9~	16.7	RCM562~	RCM98
			FqEPBSN6.2	6	5	27.51	2.47	-0.61	-0.20	1.73	27.2~	41.1	RCM98~	RCM581
			FqEPBSN6.1	6	7	7.01	2.21	-0.35	-0.56	0.13	0~	21.2	RCM1556~	RCM1523
			qEPBSN3.1	3	10	23.11	4.55	-0.64	0.16	9.38	17.8~	30.7	RCM915~	RCM950
	ICIM-	ESNPP	FqESNPP6.1	6	7	4.00	2.90	-0.55	-1.20	4.93	0~	12.5	RCM1556~	RCM1521
	ADD		qESNPP3.1	3	10	23.00	4.61	-1.14	-0.33	6.94	16.5~	31.5	RCM917~	RCM950
		EPBSN	FqEPBSN9.2	9	1	18.00	2.16	-0.33	-0.39	3.16	16.5~	18.0	RCM1336~	RCM1338
			FqEPBSN6.1	6	7	7.00	2.46	-0.40	-0.58	5.29	0~	17.5	RCM1556~	RCM1521
			qEPBSN3.1	3	10	23.00	3.25	-0.56	0.11	5.42	17.5~	33.5	RCM917~	RCM950
BC₁	CIM	ESNPP	BqESNPP7.1	7	1	1.00	5.01	2.12	-	3.52	0.4~	13.3	RCM1778~	RCM1772
			qESNPP3.1	3	4	4.00	18.81	3.61	-	6.27	12.3~	26.3	RCM950~	RCM931
		EPBSN	BqEPBSN7.1	7	1	1.00	5.01	2.31	-	4.42	2.6~	6.0	RCM1778~	RCM1625
			qEPBSN3.1	3	4	4.00	18.81	3.18	-	5.62	13.5~	26.8	RCM950~	RCM931
	ICIM-	ESNPP	qESNPP3.1	3	4	19.00	4.45	-1.96	-	7.92	12.5~	21.5	RCM920~	RCM917
	ADD	EPBSN	qEPBSN3.1	3	4	21.00	3.95	-0.87	-	7.21	17.5~	27.5	RCM920~	RCM917
S₁	CIM	EPBSN	qEPBSN3.1	3	1	15.01	2.18	-0.47	0.23	13.27	1.5~	23.5	RCM915~	RCM950

QTL_1	染色体_1 Chr_1		位置_1 Pos_1		标记区间_1 MI_1		QTL_2		染色体_2 Chr_2		位置_2 Pos_2		标记区间_2 MI_2
FqEPBSN7.1	7		15		RCM1769~RCM1843		FqEPBSN7.2		7		170		RCM550~RCM1848
LOD	贡献率/% PVE	加性_1 Add_1		加性_2 Add_2		显性_1 Dom_1		显性_2 Dom_2		AA		AD		DA	DD
5.36	2.45	0.76		-0.26		0.90		1.24		-0.15		-2.51		1.14	-2.58
