Genome-Wide Association Study of Organic Acids in Vegetable Soybean

doi:10.7668/hbnxb.20194140

Abstract

Abstract:

In order to study the organic acid synthesis mechanism of vegetable soybean and provide a theoretical basis for the quality improvement of vegetable soybean,a natural population containing 264 accessions of vegetable soybean was used as experimental materials.The contents of tartaric acid,malic acid and citric acid in this population were determined by high performance liquid chromatography(HPLC)in 2020 and 2021,respectively,and genome-wide association study was conducted based on the genotype data of this population,SNP loci and candidate genes significantly associated with organic acid content were identified.The results showed that the average content of tartaric acid in 2020 and 2021 populations were 4.13,4.16 mg/g,respectively;the average content of malic acid was 7.26,8.99 mg/g,respectively;the average content of citric acid was 7.12,10.88 mg/g,respectively.Correlation analysis showed that citric acid content of 264 materials showed a significant positive correlation between 2020 and 2021.Significant positive correlation coefficients were obtained for the pairs of malic/citric acids,tartaric/malic acids,and tartaric/citric acids were 0.790^*,0.695^*,0.739^*,respectively.The results showed that there were significant differences among different varieties in the test population,with rich genetic diversity.Six specific germplasm resources with high organic acid contents were selected to provide excellent materials for the improvement and breeding of organic acid varieties of vegetable soybean.Genome-wide association study based on the mixed linear model the number of SNP loci significantly correlated with the contents of tartaric acid,malic acid and citric acid were 54,189,43,respectively,and based on the gene functional annotation information,3 and 5 candidate genes were identified which were significantly correlated with the content of tartaric acid and malic acid,respectively.

Key words: Vegetable soybean, SNP, Genome-wide association study, Organic acid, HPLC

LIU Hui, XU Wenjing, YANG Shuo, ZHANG Wei, ZHANG Hongmei, LIU Xiaoqing, ZHU Yuelin, CHEN Huatao. Genome-Wide Association Study of Organic Acids in Vegetable Soybean[J]. Acta Agriculturae Boreali-Sinica, 2023, 38(4): 74-82. doi: 10.7668/hbnxb.20194140.

/ / Recommend / Download Citations

URL: http://www.hbnxb.net/EN/10.7668/hbnxb.20194140

http://www.hbnxb.net/EN/Y2023/V38/I4/74

Figures/Tables 14

References 20

[1]	Zhang G W, Xu S C, Mao W H, Hu Q Z, Gong Y M. Determination of the genetic diversity of vegetable soybean(Glycine max (L.)Merr.)using EST-SSR markers[J]. Journal of Zhejiang University Science B, 2013, 14(4):279-288.doi:10.1631/jzus.B1200243. doi: 10.1631/jzus.B1200243 URL
[2]	Hu R F, Zhang Y M, Chen Y H, Lin G Q. Dynamic metabolic profiling in vegetable soybean seed development[J]. Emirates Journal of Food and Agriculture, 2018, 30(2):90-98.doi:10.9755/ejfa.2018.v30.i1.1594. doi: 10.9755/ejfa.2018.v30.i1.1594
[3]	Sowalsky R A, Noble A C. Comparison of the effects of concentration,pH and anion species on astringency and sourness of organic acids[J]. Chemical Senses, 1998, 23(3):343-349.doi:10.1093/chemse/23.3.343. doi: 10.1093/chemse/23.3.343 pmid: 9669047
[4]	Baccichet I, Chiozzotto R, Bassi D, Gardana C, Cirilli M, Spinardi A. Characterization of fruit quality traits for organic acids content and profile in a large peach germplasm collection[J]. Scientia Horticulturae, 2021, 278:109865.doi:10.1016/j.scienta.2020.109865. doi: 10.1016/j.scienta.2020.109865 URL
[5]	Green B G, Lim J, Osterhoff F, Blacher K, Nachtigal D. Taste mixture interactions:Suppression,additivity,and the predominance of sweetness[J]. Physiology & Behavior, 2010, 101(5):731-737.doi:10.1016/j.physbeh.2010.08.013. doi: 10.1016/j.physbeh.2010.08.013 URL
[6]	毛岳忠. 甜酸味觉交互响应的量化研究和传感器组合研制[D]. 杭州: 浙江工商大学, 2019.doi:10.27462/d.cnki.ghzhc.2019.000208. doi: 10.27462/d.cnki.ghzhc.2019.000208
	Mao Y Z. Quantitative study on sweet and sour taste interaction response and development of sensor combination[D]. Hangzhou: Zhejiang Gongshang University, 2019.
[7]	Liebhard R, Koller B, Gianfranceschi L, Gessler C. Creating a saturated reference map for the apple(Malus (domestica Borkh.)genome[J]. Theoretical and Applied Genetics, 2003, 106(8):1497-1508.doi:10.1007/s00122-003-1209-0. doi: 10.1007/s00122-003-1209-0 pmid: 12677403
[8]	Maliepaard C, Alston F H, van Arkel G, Brown L M, Chevreau E, Dunemann F, Evans K M, Gardiner S, Guilford P, van Heusden A W, Janse J, Laurens F, Lynn J R, Manganaris A G, den Nijs A P M, Periam N, Rikkerink E, Roche P, Ryder C, Sansavini S, Schmidt H, Tartarini S, Verhaegh J J, Vrielink-van Ginkel M, King G J. Aligning male and female linkage maps of apple(Malus pumila Mill.)using multi-allelic markers[J]. Theoretical and Applied Genetics, 1998, 97(1/2):60-73.doi:10.1007/s001220050867. doi: 10.1007/s001220050867 URL
[9]	Zhang X X, Guan Z R, Wang L, Fu J, Zhang Y C, Li Z L, Ma L L, Liu P, Zhang Y L, Liu M, Li P, Zou C Y, He Y C, Lin H J, Yuan G S, Gao S B, Pan G T, Shen Y O. Combined GWAS and QTL analysis for dissecting the genetic architecture of kernel test weight in maize[J]. Molecular Genetics and Genomics, 2020, 295(2):409-420.doi:10.1007/s00438-019-01631-2. doi: 10.1007/s00438-019-01631-2 pmid: 31807910
[10]	Zhang Y J, Liu Z X, Wang X R, Li Y, Li Y S, Gou Z W, Zhao X Z, Hong H L, Ren H L, Qi X S, Qiu L J. Identification of genes for drought resistance and prediction of gene candidates in soybean seedlings based on linkage and association mapping[J]. The Crop Journal, 2022, 10(3):830-839.doi:10.1016/j.cj.2021.07.010. doi: 10.1016/j.cj.2021.07.010 URL
[11]	盖钧镒, 王明军, 陈长之. 中国毛豆生产的历史渊源与发展[J]. 大豆科学, 2002, 21(1):7-13.doi:10.3969/j.issn.1000-9841.2002.01.002. doi: 10.3969/j.issn.1000-9841.2002.01.002
	Gai J Y, Wang M J, Chen C Z. Historical origin and development of Maodou production in China[J]. Soybean Science, 2002, 21(1):7-13.
[12]	Zhang W, Xu W J, Zhang H M, Liu X Q, Cui X Y, Li S S, Song L, Zhu Y L, Chen X, Chen H T. Comparative selective signature analysis and high-resolution GWAS reveal a new candidate gene controlling seed weight in soybean[J]. Theoretical and Applied Genetics, 2021, 134(5):1329-1341.doi:10.1007/s00122-021-03774-6. doi: 10.1007/s00122-021-03774-6 pmid: 33507340
[13]	Wang J B, Zhang Z W. GAPIT version 3:boosting power and accuracy for genomic association and prediction[J]. Genomics,Proteomics and Bioinformatics, 2021, 19(4):629-640.doi:10.1016/j.gpb.2021.08.005. doi: 10.1016/j.gpb.2021.08.005
[14]	Song J F, Liu C Q, Li D J, Gu Z X. Evaluation of sugar,free amino acid,and organic acid compositions of different varieties of vegetable soybean(Glycine max[L.]Merr)[J]. Industrial Crops and Products, 2013, 50:743-749.doi:10.1016/j.indcrop.2013.08.064. doi: 10.1016/j.indcrop.2013.08.064 URL
[15]	张玉梅, 胡润芳, 林秀美, 邓红枚, 蓝新隆, 林国强. 鲜食大豆籽粒代谢物分析[J]. 耕作与栽培, 2022, 42(5):20-25.doi:10.13982/j.mfst.1673-9078.2021.6.1032. doi: 10.13982/j.mfst.1673-9078.2021.6.1032
	Zhang Y M, Hu R F, Lin X M, Deng H M, Lan X L, Lin G Q. Analysis of metabolites in vegetable soybean seeds[J]. Tillage and Cultivation, 2022, 42(5):20-25.
[16]	Yang K, Moon J K, Jeong N, Chun H K, Kang S T, Back K, Jeong S C. Novel major quantitative trait loci regulating the content of isoflavone in soybean seeds[J]. Genes & Genomics, 2011, 33(6):685-692.doi:10.1007/s13258-011-0043-z. doi: 10.1007/s13258-011-0043-z
[17]	Liu J, Zhou M X. The ALMT gene family performs multiple functions in plants[J]. Agronomy, 2018, 8(2):20.doi:10.3390/agronomy8020020. doi: 10.3390/agronomy8020020 URL
[18]	Xu L L, Qiao X, Zhang M Y, Zhang S L. Genome-Wide analysis of aluminum-activated malate transporter family genes in six Rosaceae species,and expression analysis and functional characterization on malate accumulation in Chinese white pear[J]. Plant Science, 2018, 274:451-465.doi:10.1016/j.plantsci.2018.06.022. doi: 10.1016/j.plantsci.2018.06.022 URL
[19]	Li C L, Dougherty L, Coluccio A E, Meng D, El-Sharkawy I, Borejsza-Wysocka E, Liang D, Piñeros M A, Xu K N, Cheng L L. Apple ALMT9 requires a conserved C-terminal domain for malate transport underlying fruit acidity[J]. Plant Physiology, 2020, 182(2):992-1006.doi:10.1104/pp.19.01300. doi: 10.1104/pp.19.01300 pmid: 31772076
[20]	Meyer S, Mumm P, Imes D, Endler A, Weder B, Al-Rasheid K A S, Geiger D, Marten I, Martinoia E, Hedrich R. AtALMT12 represents an R-type anion channel required for stomatal movement in Arabidopsis guard cells[J]. The Plant Journal:for Cell and Molecular Biology, 2010, 63(6):1054-1062.doi:10.1111/j.1365-313X.2010.04302.x. doi: 10.1111/j.1365-313X.2010.04302.x URL

时间/min Time	甲醇/% MeOH	0.1%磷酸水溶液/% 0.1% PBS
0	2.5	97.5
10	2.5	97.5
12	100.0	0.0
17	100.0	0.0
20	2.5	97.5
25	2.5	97.5

时间/min Time	甲醇/% MeOH	0.1%磷酸水溶液/% 0.1% PBS
0	2.5	97.5
10	2.5	97.5
12	100.0	0.0
17	100.0	0.0
20	2.5	97.5
25	2.5	97.5

有机酸 Organic acid	回归方程 Linear regression equation	相关系数(R²) Coefficient of determination	定量限/(μg/mL) Quantification limit
酒石酸 Tartaric acid	y=1 453.8x-6 643.1	0.998 2	2.5
苹果酸 Malic acid	y=715.7x-4 082.6	0.997 9	3.0
柠檬酸 Citric acid	y=1 005.8x-846.9	0.999 1	10.0

有机酸 Organic acid	回归方程 Linear regression equation	相关系数(R²) Coefficient of determination	定量限/(μg/mL) Quantification limit
酒石酸 Tartaric acid	y=1 453.8x-6 643.1	0.998 2	2.5
苹果酸 Malic acid	y=715.7x-4 082.6	0.997 9	3.0
柠檬酸 Citric acid	y=1 005.8x-846.9	0.999 1	10.0

性状 Trait	环境 Environment	最小值/ (mg/g) Min	最大值/ (mg/g) Max	均值/ (mg/g) Mean	中位数 Median	极差 Mean	标准差 s	变异系数/% CV
酒石酸	2020	1.66	9.19	4.13	3.88	7.53	1.29	31.25
Tartaric acid	2021	0.48	13.52	4.16	4.03	13.04	2.17	52.07
苹果酸	2020	1.47	36.46	7.26	6.26	34.98	4.89	67.29
Malic acid	2021	1.89	25.19	8.99	8.75	23.30	4.23	47.07
柠檬酸	2020	2.56	12.05	7.12	7.09	9.49	1.37	19.22
Citric acid	2021	1.54	18.31	10.88	11.09	16.77	2.87	26.35
