Carbon Footprint Evaluation of Cereal-bean,Cereal-potato Rotation Modes Based on Wheat-maize Cropping System in North China Plain

doi:10.7668/hbnxb.20193400

Abstract

Abstract:

Aiming at the problem of low economic efficiency and high carbon emission caused by long-term double cropping system of winter wheat-summer maize in North China Plain and facing to the arduous task of ensuring food security,this study was based on the winter wheat-summer maize rotation mode,and added sweet potato and soybean into the rotation system to form the cereal-potato and cereal-soybean rotation modes.In order to build a stable,efficient and ecological planting system suitable for this region,the experiment was conducted in Ningjin plot of Hebei Academy of Agriculture and Forestry Sciences from 2019-10 to 2021-10.There were two cropping modes: winter wheat-summer maize→fallow-spring sweet potato(cereal-sweet potato mode)and winter wheat-summer maize→winter wheat-summer soybean(cereal-soybean mode).Inter-annual repetitions were carried out at the same time,namely,fallow-spring sweet potato→winter wheat-summer maize and winter wheat-summer soybean→winter wheat-summer maize.The differences of annual equivalent yield,net benefit,carbon emission and carbon footprint under different cropping rotations were analyzed.The results showed that:Compared with wheat-maize mode,the annual equivalent yield of cereal-sweet potato mode increased by 29.10%.Meanwhile,the annual equivalent yield of cereal-soybean mode decreased by 6.03%.Cereal-sweet potato and cereal-soybean modes significantly reduced the indirect emissions caused by agricultural materials production and transportation and mainly reduced carbon emissions from chemical nitrogen fertilizers and irrigation electricity.Compared with that of CK,the reduction was 40.5% and 14.9%,respectively.Compared with that of CK,cereal-sweet potato and cereal-soybean modes reduced N₂O direct emissions caused by nitrogen fertilizer application by 50.0% and 32.4%,and indirect emissions caused by ammonia volatilization by 50.0% and 29.6%,respectively,and indirect emission caused by nitrogen leaching decreased by 50.0% and 26.4%,respectively.The annual total carbon emission of CK,cereal-sweet potato mode and cereal-soybean mode were 13 361.4,7 468.2,and 10 315.0 kg/ha,respectively.The annual total carbon emissions of cereal-sweet potato and cereal-soybean modes decreased by 44.1% and 22.8%,respectively,compared with that of the control mode.Compared with that of CK,the carbon footprint per unit area of cereal-sweet potato and cereal-soybean modes decreased by 44.1% and 22.8%,the carbon footprint per unit biomass decreased by 29.7% and 9.4%,respectively.In all,adding sweet potato and soybean to wheat-maize cropping system could reduce carbon footprint.Therefore,from the perspective of emission reduction,cereal-sweet potato and cereal-soybean modes can be recommended as a theoretical model to partially replace the traditional wheat-maize mode in North China Plain.

Key words: Cereal-sweet potato rotation, Cereal-soybean rotation, Carbon footprint

ZHENG Mengjing, ZHANG Jingting, CUI Yongzeng, YAO Haipo, JIA Xiuling, LI Yan. Carbon Footprint Evaluation of Cereal-bean,Cereal-potato Rotation Modes Based on Wheat-maize Cropping System in North China Plain[J]. Acta Agriculturae Boreali-Sinica, 2022, 37(S1): 81-89. doi: 10.7668/hbnxb.20193400.

/ / Recommend / Download Citations

URL: http://www.hbnxb.net/EN/10.7668/hbnxb.20193400

http://www.hbnxb.net/EN/Y2022/V37/IS1/81

Figures/Tables 12

References 31

[1]	Solomon S, Change I P O C. Climate change 2007: the physical science basis: contribution of working group I to the fourth assessment report of the intergovernmental panel on climate change[M]. New York: Cambridge University Press, 2007.
[2]	中华人民共和国国家统计局. 中国统计年鉴[M]. 北京: 中国统计出版社, 2021.
	National Bureau of Statistics of the People's Republic of China. China Statistical Yearbook[M]. Beijing: China Statistics Press, 2021.
[3]	巨晓棠, 谷保静. 我国农田氮肥施用现状、问题及趋势[J]. 植物营养与肥料学报, 2014, 20(4): 783-795.doi: 10.11674/zwyf.2014.0401. doi: 10.11674/zwyf.2014.0401
	Ju X T, Gu B J. Status-quo,problem and trend of nitrogen fertilization in China[J]. Journal of Plant Nutrition and Fertilizers, 2014, 20(4): 783-795.
[4]	孙志梅, 武志杰, 陈利军, 刘永刚. 农业生产中的氮肥施用现状及其环境效应研究进展[J]. 土壤通报, 2006, 37(4): 782-786.doi: 10.19336/j.cnki.trtb.2006.04.037. doi: 10.19336/j.cnki.trtb.2006.04.037
	Sun Z M, Wu Z J, Chen L J, Liu Y G. Research advances in nitrogen fertilization and its environmental effects[J]. Chinese Journal of Soil Science, 2006, 37(4): 782-786.
[5]	Qin S P, Wang Y Y, Hu C S, Oenema O, Li X X, Zhang Y M, Dong W X. Yield-scaled N₂O emissions in a winter wheat-summer corn double-cropping system[J]. Atmospheric Environment, 2012, 55: 240-244.doi: 10.1016/j.atmosenv.2012.02.077. doi: 10.1016/j.atmosenv.2012.02.077 URL
[6]	赵影星, 王彪, 刘晴, 宋彤, 张学鹏, 陈源泉, 隋鹏. 黑龙港平原基于麦-玉复种的两年轮作模式农田水分消耗特征研究[J]. 作物学报, 2022, 48(7): 1787-1799.doi: 10.3724/SP.J.1006.2022.11030. doi: 10.3724/SP.J.1006.2022.11030
	Zhao Y X, Wang B, Liu Q, Song T, Zhang X P, Chen Y Q, Sui P. Characteristics of farmland water consumption under two-year wheat-maize interannual rotation patterns in Heilonggang Plain[J]. Acta Agronomica Sinica, 2022, 48(7): 1787-1799.
[7]	Yang Y H, Zou J, Huang W H, Manevshi K, Eivind J, Rees R M, Hu S, Li W J, Kersebaum K C, Louarn G, Ferchaud F, Si J S, Xiong S P, Wen X Y, Chen F, Yin X G. Farm-scale practical strategies to increase nitrogen use efficiency and reduce nitrogen footprint in crop production across the North China Plain[J]. Field Crops Research, 2022, 283: 108526.doi: 10.1016/j.fcr.2022.108526. doi: 10.1016/j.fcr.2022.108526
[8]	Park S E, Webster T J, Horan H L, James A T, Thorburn P J. A legume rotation crop lessens the need for nitrogen fertiliser throughout the sugarcane cropping cycle[J]. Field Crops Research, 2010, 119(213): 331-341.doi: 10.1016/j.fcr.2010.08.001. doi: 10.1016/j.fcr.2010.08.001 URL
[9]	Herridge D F, Peoples M B, Boddey R M. Global inputs of biological nitrogen fixation in agricultural systems[J]. Plant and Soil, 2008, 311(1): 1-18.doi: 10.1007/s11104-008-9668-3. doi: 10.1007/s11104-008-9668-3 URL
[10]	Preissel S, Reckling M, Schläfke N, Zander P. Magnitude and farm-economic value of grain legume pre-crop benefits in Europe: a review[J]. Field Crops Research, 2015, 175: 64-79.doi: 10.1016/j.fcr.2015.01.012. doi: 10.1016/j.fcr.2015.01.012 URL
[11]	Reckling M, Hecker J M, Bergkvist G, Watson C A, Zander P, Schläfke N, Stoddard F L, Eory V, Topp C F E, Maire J, Bachinger J. A cropping system assessment framework-Evaluating effects of introducing legumes into crop rotations[J]. European Journal of Agronomy, 2016, 76: 186-197.doi: 10.1016/j.eja.2015.11.005. doi: 10.1016/j.eja.2015.11.005 URL
[12]	Behnke G B, Zuber S M, Pittelkow C M, Nafziger E D, Villamil M B. Long-term crop rotation and tillage effects on soil greenhouse gas emissions and crop production in Illinois,USA[J]. Agriculture,Ecosystems & Environment, 2018, 261: 62-70.doi: 10.1016/j.agee.2018.03.007. doi: 10.1016/j.agee.2018.03.007
[13]	Zhao Y X, Wang L, Lei X Y, Wang B, Cui J X, Xu Y N, Chen Y Q, Sui P. Reducting carbon footprint without compromising grain security through relaxing cropping rotation system in the North China Plain[J]. Journal of Cleaner Production, 2021, 318:128465.doi: 10.1016/j.jclepro.2021.128465. doi: 10.1016/j.jclepro.2021.128465
[14]	Gan Y, Liang C, Chai Q, Lemke R L, Campbell C A, Zentner R P. Improving farming practices reduces the carbon footprint of spring wheat production[J]. Nat Commun, 2014, 5: 5012. doi:10.1038/ncomms6012. doi: 10.1038/ncomms6012 pmid: 25405548
[15]	朱永昶, 李玉娥, 姜德锋, 邹晓霞. 基于生命周期评估的冬小麦-夏玉米种植系统碳足迹核算--以山东省高密地区为例[J]. 农业资源与环境学报, 2017, 34(5): 473-482.doi: 10.13254/j.jare.2017.0180 doi: 10.13254/j.jare.2017.0180
	Zhu Y C, Li Y, Jiang D F, Zou X X. Life cycle assessment on carbon footprint of winter wheat-summer maize cropping system based on survey data of Gaomi in Shandong Province,China[J]. Journal of Agricultural Resources and Environment, 2017, 34(5): 473-482.
[16]	王占彪, 陈静, 张立峰, 陈阜, 孙红春, 刘连涛, 宋文, 李存东, 李亚兵. 河北省棉花生产碳足迹分析[J]. 棉花学报, 2016, 28(6): 594-601.doi: 10.11963/issn.1002-7807.201606009. doi: 10.11963/issn.1002-7807.201606009
	Wang Z B, Chen J, Zhang L F, Chen F, Sun H C, Liu L T, Song W, Li C D, Li Y B. Carbon footprint analysis of cotton production in Hebei Province[J]. Cotton Science, 2016, 28(6): 594-601.
[17]	杨晓琳. 华北平原不同轮作模式节水减排效果评价[D]. 北京: 中国农业大学, 2015.
	Yang X L. Effects of diversified crop rotations on conserving ground water resource and lowering carbon footprint in the North China Plain[D]. Beijing: China Agricultural University, 2015.
[18]	Liu Q Y, Xu C T, Han S W, Li X X, Kan Z R, Zhao X, Zhang H L. Strategic tillage achieves lower carbon footprints with higher carbon accumulation and grain yield in a wheat-maize cropping system[J]. The Science of the Total Environment, 2021, 798: 149220. doi:10.1016/j.scitotenv.2021.149220. doi: 10.1016/j.scitotenv.2021.149220
[19]	Edenhofer O. Climate change 2014: mitigation of climate change: Working Group III contribution to the fifth assessment report of the intergovernmental panel on climate change[M]. Geneva,Switzerland:IPCC, 2014,151.
[20]	Liu K, Blackshaw R E, Johnson E N, Hossain Z, Hamel C, St-arnaud M, Gan Y T. Lentil enhances the productivity and stability of oilseed-cereal cropping systems across different environments[J]. European Journal of Agronomy, 2019, 105: 24-31.doi: 10.1016/j.eja.2019.02.005. doi: 10.1016/j.eja.2019.02.005 URL
[21]	王翠娟, 史春余, 王振振, 柴沙沙, 柳洪鹃, 史衍玺. 覆膜栽培对甘薯幼根生长发育、块根形成及产量的影响[J]. 作物学报, 2014, 40(9): 1677-1685.doi: 10.3724/SP.J.1006.2014.01677. doi: 10.3724/SP.J.1006.2014.01677
	Wang C J, Shi C Y, Wang Z Z, Chai S S, Liu H J, Shi Y X. Effects of plastic film mulching cultivation on young roots growth development,Tuber formation and Tuber yield of sweet potato[J]. Acta Agronomica Sinica, 2014, 40(9): 1677-1685. doi: 10.3724/SP.J.1006.2014.01677 URL
[22]	江燕, 史春余, 王振振, 王翠娟, 柳洪鹃. 地膜覆盖对耕层土壤温度水分和甘薯产量的影响[J]. 中国生态农业学报, 2014, 22(6): 627-634.doi: 10.3724/SP.J.1011.2014.31229. doi: 10.3724/SP.J.1011.2014.31229
	Jiang Y, Shi C Y, Wang Z Z, Wang C J, Liu H J. Effects of plastic film mulching on arable layer soil temperature,moisture and yield of sweet potato[J]. Chinese Journal of Eco-Agriculture, 2014, 22(6): 627-634.
[23]	曾昭海, 褚庆全, 赵晓萌, 胡跃高, 卢成, 康玉凡. 我国大豆产业发展趋势与对策[J]. 中国农业科技导报, 2005, 7(6): 43-48.doi: 1008-0864(2005)06-0043-06. URL
	Zeng Z H, Chu Q Q, Zhao X M, Hu Y G, Lu C, Kang Y F. The present situation,problems and comtermeasures of soybean production in China[J]. Review of China Agricultural Science and Technology, 2005, 7(6): 43-48.
[24]	Zhu X C, Zhang J, Zhang Z P, Deng A X, Zhang W J. Dense planting with less basal nitrogen fertilization might benefit rice cropping for high yield with less environmental impacts[J]. European Journal of Agronomy, 2016, 75: 50-59.doi: 10.1016/j.eja.2016.01.003. doi: 10.1016/j.eja.2016.01.003 URL
[25]	Chen H, Zheng C Y, Chen F, Qiao Y Q, Du S Q, Cao C F, Zhang W J. Less N₂O emission from newly high-yielding cultivars of winter wheat[J]. Agriculture, Ecosystems & Environment, 2021, 320: 107557.doi: 10.1016/j.agee.2021.107557. doi: 10.1016/j.agee.2021.107557
[26]	Yan M, Cheng K, Luo T, Yan Y, Pan G X, Rees R M. Carbon footprint of grain crop production in China-based on farm survey data[J]. Journal of Cleaner Production, 2015, 104: 130-138.doi: 10.1016/j.jclepro.2015.05.058. doi: 10.1016/j.jclepro.2015.05.058 URL
[27]	王上, 李康利, 聂江文, 杨亚东, 臧华栋, 曾昭海. 华北平原春绿豆-夏玉米种植模式经济效益和碳足迹评价[J]. 中国生态农业学报(中英文), 2020, 28(6): 910-919.doi: 10.13930/j.cnki.cjea.190916. doi: 10.13930/j.cnki.cjea.190916
	Wang S, Li K L, Nie J W, Yang Y D, Zang H D, Zeng Z H. Economic benefits and carbon footprint of a spring mung bean-summer maize cropping system in the North China Plain[J]. Chinese Journal of Eco-Agriculure, 2020, 28(6): 910-919.
[28]	Liu C, Plaza-bonilla D, Coulter J A, Kutcher H R, Beckie H J, Wang L, Floc'h G B, Hamel C, Siddique K H M, Li L L, Gan Y T. Chapters six-Diversifying crop rotations enhances agroecosystem services and resilience[J]. Advances in Agronmy, 2022, 173: 299-335.doi: 10.1016/bs.agron.2022.02.007. doi: 10.1016/bs.agron.2022.02.007
[29]	姜雨林, 陈中督, 遆晋松, 隋鹏, 陈阜. 华北平原不同轮作模式固碳减排模拟研究[J]. 中国农业大学学报, 2018, 23(1): 19-26.doi: 10.11841/j.issn.1007-4333.2018.01.03. doi: 10.11841/j.issn.1007-4333.2018.01.03
	Jiang Y L, Chen Z D, Ti J S, Sui P, Chen F. Simulation of soil carbon storage and greenhouse gas emission under different rotation systems in the North China Plain[J]. Journal of China Agricultural University, 2018, 23(1): 19-26.
[30]	黄少辉, 杨军芳, 杨云马, 姜蓉, 何萍, 贾良良. 长期应用养分专家管理模式提高小麦玉米轮作氮肥利用率及土壤有机碳固存[J]. 华北农学报, 2021, 36(2):154-161. doi:10.7668/hbnxb.20191841. doi: 10.7668/hbnxb.20191841
	Huang S H, Yang J F, Yang Y M, Jiang R, He P, Jia L L. Long-term nutrient expert management improves nitrogen use efficiency and enhances soil organic carbon sequestration in wheat-maize rotation system[J]. Acta Agriculturae Boreali-Sinica, 2021, 36(2):154-161. doi: 10.7668/hbnxb.20191841
[31]	Yang X L, Gao W S, Zhang M, Chen Y Q, Sui P. Reducing agricultural carbon footprint through diversified crop rotation systems in the North China Plain[J]. Journal of Cleaner Production, 2014, 76: 131-139.doi: 10.1016/j.jclepro.2014.03.063. doi: 10.1016/j.jclepro.2014.03.063 URL

项目 Items	投入量/(kg/hm²) Input amount				温室气体排放参数/(kg/hm²) GHG emission coefficients			转换系数 /(CO₂-eq) CO₂ equivalent conversion coefficients
项目 Items	冬小麦 Winter wheat	夏玉米 Summer maize	夏大豆 Summer soybean	春甘薯 Sweet potato	CO₂	N₂O	CH₄	转换系数 /(CO₂-eq) CO₂ equivalent conversion coefficients
氮肥 N fertilizer	210.00	240.00	67.50	0.00	10.13	0.000 17	0.000 24	10.18
磷肥 P fertilizer	108.00	23.10	42.00	0.00	1.50	0.000 02	0.000 02	1.50
钾肥 K fertilizer	36.00	75.00	21.00	117.00	0.97	0.000 03	0.000 04	0.98
农用地膜 Mulch film	0.00	0.00	0.00	90.00	-	-	-	2.27
农药 Pesticides	3.00	4.50	3.00	36.00	-	-	-	18.00
电力 Electricity	810.00	540.00	270.00	270.00	0.95	0.000 01	0.000 01	0.95
柴油 Diesel	52.00	40.00	40.00	20.00	3.88	0.000 14	0.000 65	3.93
小麦种子 Wheat seeds	225.00	0.00	0.00	0.00	-	-	-	1.16
玉米种子 Maize seeds	0.00	22.28	0.00	0.00	-	-	-	1.22
大豆种子 Soybean seeds	0.00	0.00	75.00	0.00	-	-	-	0.34
甘薯种苗 Sweet potato seedlings	0.00	0.00	0.00	150.00	-	-	-	0.10

项目 Items	投入量/(kg/hm²) Input amount				温室气体排放参数/(kg/hm²) GHG emission coefficients			转换系数 /(CO₂-eq) CO₂ equivalent conversion coefficients
项目 Items	冬小麦 Winter wheat	夏玉米 Summer maize	夏大豆 Summer soybean	春甘薯 Sweet potato	CO₂	N₂O	CH₄	转换系数 /(CO₂-eq) CO₂ equivalent conversion coefficients
氮肥 N fertilizer	210.00	240.00	67.50	0.00	10.13	0.000 17	0.000 24	10.18
磷肥 P fertilizer	108.00	23.10	42.00	0.00	1.50	0.000 02	0.000 02	1.50
钾肥 K fertilizer	36.00	75.00	21.00	117.00	0.97	0.000 03	0.000 04	0.98
农用地膜 Mulch film	0.00	0.00	0.00	90.00	-	-	-	2.27
农药 Pesticides	3.00	4.50	3.00	36.00	-	-	-	18.00
电力 Electricity	810.00	540.00	270.00	270.00	0.95	0.000 01	0.000 01	0.95
柴油 Diesel	52.00	40.00	40.00	20.00	3.88	0.000 14	0.000 65	3.93
小麦种子 Wheat seeds	225.00	0.00	0.00	0.00	-	-	-	1.16
玉米种子 Maize seeds	0.00	22.28	0.00	0.00	-	-	-	1.22
大豆种子 Soybean seeds	0.00	0.00	75.00	0.00	-	-	-	0.34
甘薯种苗 Sweet potato seedlings	0.00	0.00	0.00	150.00	-	-	-	0.10

项目 Items	农资投入导致的间接排放量 Indirect emission amount induced by agriculture input
项目 Items	冬小麦 Winter wheat	夏玉米 Summer maize	夏大豆 Summer soybean	春甘薯 Spring sweet potato
氮肥 N fertilizer	2 138.46	2 443.95	687.36	0.00
磷肥 P fertilizer	162.26	34.70	63.10	0.00
钾肥 K fertilizer	35.39	73.74	20.65	115.03
农用地膜 Mulch film	0.00	0.00	0.00	204.48
农药 Pesticides	54.00	81.00	54.00	648.00
电力 Electricity	770.91	513.94	256.97	256.97
柴油 Diesel	204.51	157.31	157.31	78.66
小麦种子 Wheat seeds	261.00	0.00	0.00	0.00
玉米种子 Maize seeds	0.00	27.18	0.00	0.00
大豆种子 Soybean seeds	0.00	0.00	25.65	0.00
甘薯种苗 Sweet potato seedlings	0.00	0.00	0.00	15.00

项目 Items	农资投入导致的间接排放量 Indirect emission amount induced by agriculture input
项目 Items	冬小麦 Winter wheat	夏玉米 Summer maize	夏大豆 Summer soybean	春甘薯 Spring sweet potato
氮肥 N fertilizer	2 138.46	2 443.95	687.36	0.00
磷肥 P fertilizer	162.26	34.70	63.10	0.00
钾肥 K fertilizer	35.39	73.74	20.65	115.03
农用地膜 Mulch film	0.00	0.00	0.00	204.48
农药 Pesticides	54.00	81.00	54.00	648.00
电力 Electricity	770.91	513.94	256.97	256.97
柴油 Diesel	204.51	157.31	157.31	78.66
小麦种子 Wheat seeds	261.00	0.00	0.00	0.00
玉米种子 Maize seeds	0.00	27.18	0.00	0.00
大豆种子 Soybean seeds	0.00	0.00	25.65	0.00
甘薯种苗 Sweet potato seedlings	0.00	0.00	0.00	15.00

年度 Year	作物类型 Crop type	生物量/(kg/hm²) Biomass amount
2019-2020	冬小麦	11 761.92±59.47a
	夏玉米	9 522.70±67.16b
	春甘薯	12 230.34±84.19a
	夏大豆	2 235.81±76.94c
2020-2021	冬小麦	11 462.50±103.85a
	夏玉米	9 236.17±83.59b
	春甘薯	11 963.26±97.46a
	夏大豆	2 572.50±43.27c
