多毛番茄DCL、AGO和RDR基因家族全基因组鉴定及其对番茄褪绿病毒感染和非生物胁迫响应的分析

doi:10.7668/hbnxb.20195145

摘要/Abstract

摘要：

对多毛番茄全基因组的Dicer-like(DCL)、Argonaute(AGO)和RNA依赖性RNA聚合酶(RDR)基因家族进行生物信息学和表达模式分析,为深入研究DCL、AGO和RDR基因家族在多毛番茄响应非生物胁迫和病毒感染过程中的功能提供参考。以拟南芥DCL、AGO和RDR基因为参考序列,利用本地Perl语言和Pfam、SMART等软件检索多毛番茄LA1777基因组并确定多毛番茄DCL、AGO和RDR基因家族成员。通过ExPASy、GSDS 2.0、MEGA、Tbtools、SWISS-MODEL等工具对多毛番茄DCL、AGO和RDR家族基因进行生物信息学分析。根据非生物胁迫、番茄褪绿病毒(ToCV)处理和实时荧光定量PCR技术分析该类基因的表达模式。从多毛番茄中鉴定得到7个ShDCL、15个ShAGO和6个ShRDR基因,分别分布在第5,7,6条染色体上,其编码的蛋白与其他植物DCL、AGO和RDR结构相似,均含有该家族特有的保守结构域。系统发育分析表明,这些基因被分为4个亚组,与普通番茄之间具有较高的结构和功能相似性。ShDCL2a、ShDCL2c、ShDCL3、ShDCL4、ShAGO1b、ShAGO3、ShAGO4b、ShAGO5、ShAGO7、ShAGO10a、ShAGO10b、ShRDR1、ShRDR2、ShRDR3a、ShRDR6a和ShRDR6b在多种非生物胁迫和ToCV感染后显著上调表达,推测这些基因在非生物胁迫和病毒侵染过程中发挥着重要作用。

关键词: 多毛番茄, DCL, AGO, RDR, 非生物胁迫, 番茄褪绿病毒(ToCV)

Abstract:

Bioinformatics and expression patterns of Dicer-like(DCL),Argonaute(AGO)and RNA-dependent RNA polymerase(RDR)gene families in the whole genome of Solanum habrochaites were analyzed,so as to provide references for further study on the functions of DCL,AGO and RDR gene families in the response of S.habrochaites to abiotic and viral infection.Using Arabidopsis thaliana DCL,AGO and RDR genes as reference sequences,the genome of S.habrochaites LA1777 was searched by local perl language and software such as Pfam and SMART,and the members of ShDCL,ShAGO and ShRDR gene families were determined.Bioinformatics analysis of DCL,AGO and RDR family genes in S.habrochaites was carried out by means of ExPASy,GSDS 2.0,MEGA,Tbtools and SWISS-MODEL.According to abiotic stress treatment,Tomato chlorosis virus(ToCV)treatment and Real-time Fluorescence Quantitative PCR technology,the expression patterns of these genes were analyzed.Seven ShDCL,15 ShAGO and 6 ShRDR genes were identified from S.habrochaites,which were distributed on chromosome 5,7 and 6 respectively.The encoded proteins were similar in structure to DCL,AGO and RDR in other plants,and all of them contained conserved domains unique to this family.Phylogenetic analysis showed that these genes were divided into 4 subgroups,and there were high structural and functional similarities between S.habrochaites and S.lycopersicum.ShDCL2a,ShDCL2c,ShDCL3,ShDCL4,ShAGO1b,ShAGO3,ShAGO4b,ShAGO5,ShAGO7,ShAGO10a,ShAGO10b,ShRDR1,ShRDR2,ShRDR3a,ShRDR6a and ShRDR6b were significantly up-regulated after various abiotic stresses and ToCV infection.It is speculated that these genes play important roles in abiotic stress and virus infection.

Key words: Solanum habrochaites, DCL, AGO, RDR, Abiotic stress, Tomato chlorosis virus(ToCV)

康忱, 田哲娟, 高亢, 郝玲玉, 刘伟, 李亚栋, 吴志明. 多毛番茄DCL、AGO和RDR基因家族全基因组鉴定及其对番茄褪绿病毒感染和非生物胁迫响应的分析[J]. 华北农学报, 2024, 39(6): 1-17. doi: 10.7668/hbnxb.20195145.

KANG Chen, TIAN Zhejuan, GAO Kang, HAO Lingyu, LIU Wei, LI Yadong, WU Zhiming. Genome-wide Identification of Dicer-like,Argonaute and RNA-dependent RNA Polymerase Gene Families and Their Expression Analyses in Response to ToCV Infection and Abiotic Stresses in Solanum habrochaites[J]. Acta Agriculturae Boreali-Sinica, 2024, 39(6): 1-17. doi: 10.7668/hbnxb.20195145.

http://www.hbnxb.net/CN/Y2024/V39/I6/1

图/表 13

参考文献 70

[1]	Qi X P, Bao F S, Xie Z X. Small RNA deep sequencing reveals role for Arabidopsis thaliana RNA-dependent RNA polymerases in viral siRNA biogenesis[J]. PLoS One, 2009, 4(3):e4971.doi:10.1371/journal.pone.0004971.
[2]	Qin L, Mo N, Muhammad T, Liang Y. Genome-wide analysis of DCL,AGO,and RDR gene families in pepper(Capsicum annuum L.)[J]. International Journal of Molecular Sciences, 2018, 19(4):1038.doi:10.3390/ijms19041038.
[3]	Venema J H, Linger P, van Heusden A W, van Hasselt P R, Brüggemann W. The inheritance of chilling tolerance in tomato(Lycopersicon spp.)[J]. Plant Biology, 2005, 7(2):118-130.doi:10.1055/s-2005-837495. pmid: 15822007
[4]	Rick C M. Potential genetic resources in tomato species:clues from observations in native habitats[J]. Basic Life Sciences, 1973,2:255-269.doi:10.1007/978-1-4684-2880-3_17.
[5]	Chapman E J, Carrington J C. Specialization and evolution of endogenous small RNA pathways[J]. Nature Reviews Genetics, 2007, 8(11):884-896.doi:10.1038/nrg2179. pmid: 17943195
[6]	Bologna N G, Voinnet O. The diversity,biogenesis,and activities of endogenous silencing small RNAs in Arabidopsis[J]. Annual Review of Plant Biology, 2014,65:473-503.doi:10.1146/annurev-arplant-050213-035728.
[7]	López-Gomollón S, Dalmay T. Recent patents in RNA silencing in plants:constructs,methods and applications in plant biotechnology[J]. Recent Patents on DNA & Gene Sequences, 2010, 4(3):155-166.doi:10.2174/187221510794751677.
[8]	Axtell M J. Classification and comparison of small RNAs from plants[J]. Annual Review of Plant Biology, 2013,64:137-159.doi:10.1146/annurev-arplant-050312-120043.
[9]	Molnár A, Csorba T, Lakatos L, Várallyay E, Lacomme C, Burgyán J. Plant virus-derived small interfering RNAs originate predominantly from highly structured single-stranded viral RNAs[J]. Journal of Virology, 2005, 79(12):7812-7818.doi:10.1128/JVI.79.12.7812-7818.2005.
[10]	Pantaleo V, Szittya G, Burgyán J. Molecular bases of viral RNA targeting by viral small interfering RNA-programmed RISC[J]. Journal of Virology, 2007, 81(8):3797-3806.doi:10.1128/JVI.02383-06. pmid: 17267504
[11]	Kasschau K D, Fahlgren N, Chapman E J, Sullivan C M, Cumbie J S, Givan S A, Carrington J C. Genome-wide profiling and analysis of Arabidopsis siRNAs[J]. PLoS Biology, 2007, 5(3):e57.doi:10.1371/journal.pbio.0050057. pmid: 17298187
[12]	Bai M, Yang G S, Chen W T, Mao Z C, Kang H X, Chen G H, Yang Y H, Xie B Y. Genome-wide identification of Dicer-like,Argonaute and RNA-dependent RNA polymerase gene families and their expression analyses in response to viral infection and abiotic stresses in Solanum lycopersicum[J]. Gene, 2012, 501(1):52-62.doi:10.1016/j.gene.2012.02.009.
[13]	Gan D F, Zhan M D, Yang F, Zhang Q Q, Hu K L, Xu W J, Lu Q H, Zhang L, Liang D D. Expression analysis of argonaute,Dicer-like,and RNA-dependent RNA polymerase genes in cucumber(Cucumis sativus L.)in response to abiotic stress[J]. Journal of Genetics, 2017, 96(2):235-249.doi:10.1007/s12041-017-0758-y.
[14]	Kapoor M, Arora R, Lama T, Nijhawan A, Khurana J P, Tyagi A K, Kapoor S. Genome-wide identification,organization and phylogenetic analysis of Dicer-like,Argonaute and RNA-dependent RNA polymerase gene families and their expression analysis during reproductive development and stress in rice[J]. BMC Genomics, 2008,9:451.doi:10.1186/1471-2164-9-451.
[15]	Akond Z, Rahman H, Ahsan M A, Mosharaf M P, Alam M, Mollah M N H. Bioinformatic analysis based genome-wide identification,characterization,diversification and regulatory transcription components of RNA silencing machinery genes in wheat(Triticum aestivum L.)[J]. Cold Spring Harbor Laboratory, 2020.doi:10.1101/2020.05.21.108100.
[16]	Qian Y X, Cheng Y, Cheng X, Jiang H Y, Zhu S W, Cheng B J. Identification and characterization of Dicer-like,Argonaute and RNA-dependent RNA polymerase gene families in maize[J]. Plant Cell Reports, 2011, 30(7):1347-1363.doi:10.1007/s00299-011-1046-6.
[17]	Yadav C B, Muthamilarasan M, Pandey G, Prasad M. Identification,characterization and expression profiling of Dicer-like,Argonaute and RNA-dependent RNA polymerase gene families in foxtail millet[J]. Plant Molecular Biology Reporter, 2015, 33(1):43-55.doi:10.1007/s11105-014-0736-y.
[18]	Zhao H L, Zhao K, Wang J, Chen X, Chen Z, Cai R H, Xiang Y. Comprehensive analysis of Dicer-like,Argonaute,and RNA-dependent RNA polymerase gene families in grapevine(Vitis vinifera)[J]. Journal of Plant Growth Regulation, 2015, 34(1):108-121.doi:10.1007/s00344-014-9448-7.
[19]	Cao J Y, Xu Y P, Li W, Li S S, Rahman H, Cai X Z. Genome-wide identification of Dicer-like,Aargonaute,and RNA-dependent RNA polymerase gene families in Brassica species and functional analyses of their Arabidopsis homologs in resistance to Sclerotinia sclerotiorum[J]. Frontiers in Plant Science, 2016,7:1614.doi:10.3389/fpls.2016.01614.
[20]	Margis R, Fusaro A F, Smith N A, Curtin S J, Watson J M, Finnegan E J, Waterhouse P M. The evolution and diversification of Dicers in plants[J]. FEBS Letters, 2006, 580(10):2442-2450.doi:10.1016/j.febslet.2006.03.072. pmid: 16638569
[21]	Hutvagner G, Simard M J. Argonaute proteins:key players in RNA silencing[J]. Nature Reviews Molecular Cell Biology, 2008, 9(1):22-32.doi:10.1038/nrm2321. pmid: 18073770
[22]	Henderson I R, Zhang X Y, Lu C, Johnson L, Meyers B C, Green P J, Jacobsen S E. Dissecting Arabidopsis thaliana DICER function in small RNA processing,gene silencing and DNA methylation patterning[J]. Nature Genetics, 2006, 38(6):721-725.doi:10.1038/ng1804. pmid: 16699516
[23]	Liu B, Li P C, Li X, Liu C Y, Cao S Y, Chu C C, Cao X F. Loss of function of OsDCL1 affects microRNA accumulation and causes developmental defects in rice[J]. Plant Physiology, 2005, 139(1):296-305.doi:10.1104/pp.105.063420. pmid: 16126864
[24]	Vaucheret H. Plant argonautes[J]. Trends in Plant Science, 2008, 13(7):350-358.doi:10.1016/j.tplants.2008.04.007. pmid: 18508405
[25]	Pumplin N, Voinnet O. RNA silencing suppression by plant pathogens:defence,counter-defence and counter-counter-defence[J]. Nature Reviews Microbiology, 2013, 11(11):745-760.doi:10.1038/nrmicro3120. pmid: 24129510
[26]	Schuck J, Gursinsky T, Pantaleo V, Burgyán J, Behrens S E. AGO/RISC-mediated antiviral RNA silencing in a plant in vitro system[J]. Nucleic Acids Research, 2013, 41(9):5090-5103.doi:10.1093/nar/gkt193. pmid: 23535144
[27]	Huang Y W, Hu C C, Tsai C H, Lin N S, Hsu Y H. Nicotiana benthamiana Argonaute10 plays a pro-viral role in Bamboo mosaic virus infection[J]. New Phytologist, 2019, 224(2):804-817.doi:10.1111/nph.16048. pmid: 31283838
[28]	Morel J B, Godon C, Mourrain P, Béclin C, Boutet S, Feuerbach F, Proux F, Vaucheret H. Fertile hypomorphic ARGONAUTE(ago1)mutants impaired in post-transcriptional gene silencing and virus resistance[J]. The Plant Cell, 2002, 14(3):629-639.doi:10.1105/tpc.010358.
[29]	Qu F, Ye X H, Morris T J. Arabidopsis DRB4,AGO1,AGO7,and RDR6 participate in a DCL4-initiated antiviral RNA silencing pathway negatively regulated by DCL1[J]. Proceedings of the National Academy of Sciences of the United States of America, 2008, 105(38):14732-14737.doi:10.1073/pnas.0805760105.
[30]	Wang X B, Jovel J, Udomporn P, Wang Y, Wu Q F, Li W X, Gasciolli V, Vaucheret H, Ding S W. The 21-nucleotide,but not 22-nucleotide,viral secondary small interfering RNAs direct potent antiviral defense by two cooperative argonautes in Arabidopsis thaliana[J]. The Plant Cell, 2011, 23(4):1625-1638.doi:10.1105/tpc.110.082305.
[31]	Alazem M, He M H, Moffett P, Lin N S. Abscisic acid induces resistance against Bamboo mosaic virus through argonaute 2 and 3[J]. Plant Physiology, 2017, 174(1):339-355.doi:10.1104/pp.16.00015. pmid: 28270624
[32]	Borges F, Pereira P A, Slotkin R K, Martienssen R A, Becker J D. MicroRNA activity in the Arabidopsis male germline[J]. Journal of Experimental Botany, 2011, 62(5):1611-1620.doi:10.1093/jxb/erq452.
[33]	Donaire L, Barajas D, Martínez-García B, Martínez-Priego L, Pagán I, Llave C. Structural and genetic requirements for the biogenesis of tobacco rattle virus-derived small interfering RNAs[J]. Journal of Virology, 2008, 82(11):5167-5177.doi:10.1128/JVI.00272-08. pmid: 18353962
[34]	Schiebel W, P lissier T, Riedel L, Thalmeir S, Schiebel R, Kempe D, Lottspeich F, Sänger H L, Wassenegger M. Isolation of an RNA-directed RNA polymerase-specific cDNA clone from tomato[J]. The Plant Cell, 1998, 10(12):2087-2101.doi:10.1105/tpc.10.12.2087.
[35]	Lefkowitz E J, Dempsey D M, Hendrickson R C, Orton R J, Siddell S G, Smith D B. Virus taxonomy:the database of the international committee on taxonomy of viruses(ICTV)[J]. Nucleic Acids Research, 2018, 46(D1):D708-D717.doi:10.1093/nar/gkx932.
[36]	邹林峰, 涂丽琴, 沈建国, 杜振国, 蔡伟, 季英华, 高芳銮. 番茄褪绿病毒的进化动态与适应性进化特征[J]. 中国农业科学, 2020, 53(23):4791-4801.doi:10.3864/j.issn.0578-1752.2020.23.006.
	Zou L F, Tu L Q, Shen J G, Du Z G, Cai W, Ji Y H, Gao F L. The evolutionary dynamics and adaptive evolution of Tomato chlorosis virus[J]. Scientia Agricultura Sinica, 2020, 53(23):4791-4801.
[37]	Díaz-Pendón J A, Ding S W. Direct and indirect roles of viral suppressors of RNA silencing in pathogenesis[J]. Annual Review of Phytopathology, 2008, 46:303-326.doi:10.1146/annurev.phyto.46.081407.104746. pmid: 18680427
[38]	Ding S W. RNA-based antiviral immunity[J]. Nature Reviews Immunology, 2010, 10(9):632-644.doi:10.1038/nri2824.
[39]	Valli A, Dujovny G, García J A. Protease activity,self interaction,and small interfering RNA binding of the silencing suppressor P1b from Cucumber vein yellowing ipomovirus[J]. Journal of Virology, 2008, 82(2):974-986.doi:10.1128/JVI.01664-07.
[40]	Carmell M A, Hannon G J. RNase Ⅲ enzymes and the initiation of gene silencing[J]. Nature Structural & Molecular Biology, 2004, 11(3):214-218.doi:10.1038/nsmb729.
[41]	Sijen T, Fleenor J, Simmer F, Thijssen K L, Parrish S, Timmons L, Plasterk R H A, Fire A. On the role of RNA amplification in dsRNA-triggered gene silencing[J]. Cell, 2001, 107(4):465-476.doi:10.1016/s0092-8674(01)00576-1. pmid: 11719187
[42]	Groβhans H, Filipowicz W. The expanding world of small RNAs[J]. Nature, 2008, 451(7177):414-416.doi:10.1038/451414a.
[43]	Schauer S E, Jacobsen S E, Meinke D W, Ray A. Dicer-like1:blind men and elephants in Arabidopsis development[J]. Trends in Plant Science, 2002, 7(11):487-491.doi:10.1016/s1360-1385(02)02355-5.
[44]	Carmell M A, Xuan Z Y, Zhang M Q, Hannon G J. The Argonaute family:tentacles that reach into RNAi,developmental control,stem cell maintenance,and tumorigenesis[J]. Genes & Development, 2002, 16(21):2733-2742.doi:10.1101/gad.1026102.
[45]	Lingel A, Simon B, Izaurralde E, Sattler M. Nucleic acid 3'-end recognition by the Argonaute2 PAZ domain[J]. Nature Structural & Molecular Biology, 2004, 11(6):576-577.doi:10.1038/nsmb777.
[46]	Baumberger N, Baulcombe D C. Arabidopsis ARGONAUTE1 is an RNA Slicer that selectively recruits microRNAs and short interfering RNAs[J]. Proceedings of the National Academy of Sciences of the United States of America, 2005, 102(33):11928-11933.doi:10.1073/pnas.0505461102. pmid: 16081530
[47]	Carbonell A, Fahlgren N, Garcia-Ruiz H, Gilbert K B, Montgomery T A, Nguyen T, Cuperus J T, Carrington J C. Functional analysis of three Arabidopsis ARGONAUTES using slicer-defective mutants[J]. The Plant Cell, 2012, 24(9):3613-3629.doi:10.1105/tpc.112.099945. pmid: 23023169
[48]	Manavella P A, Weigel D, Wu L. Argonaute10 as a miRNA locker[J]. Cell, 2011, 145(2):173-174.doi:10.1016/j.cell.2011.03.045. pmid: 21496638
[49]	Agrawal N, Dasaradhi P V N, Mohmmed A, Malhotra P, Bhatnagar R K, Mukherjee S K. RNA interference:biology,mechanism,and applications[J]. Microbiology and Molecular Biology Reviews, 2003, 67(4):657-685.doi:10.1128/MMBR.67.4.657-685.2003.
[50]	Lingel A, Izaurralde E. RNAi:finding the elusive endonuclease[J]. RNA, 2004, 10(11):1675-1679.doi:10.1261/rna.7175704.
[51]	Xie Z, Zhang Z L, Zou X L, Huang J, Ruas P, Thompson D, Shen Q J. Annotations and functional analyses of the rice WRKY gene superfamily reveal positive and negative regulators of abscisic acid signaling in aleurone cells[J]. Plant Physiology, 2005, 137(1):176-189.doi:10.1104/pp.104.054312. pmid: 15618416
[52]	Qu D H, Show P L, Miao X L. Transcription factor ChbZIP1 from alkaliphilic microalgae Chlorella sp.BLD enhancing alkaline tolerance in transgenic Arabidopsis thaliana[J]. International Journal of Molecular Sciences, 2021, 22(5):2387.doi:10.3390/ijms22052387.
[53]	Mur L A J, Kenton P, Atzorn R, Miersch O, Wasternack C. The outcomes of concentration-specific interactions between salicylate and jasmonate signaling include synergy,antagonism,and oxidative stress leading to cell death[J]. Plant Physiology, 2006, 140(1):249-262.doi:10.1104/pp.105.072348.
[54]	Bostock R M. Signal crosstalk and induced resistance:straddling the line between cost and benefit[J]. Annual Review of Phytopathology, 2005, 43:545-580.doi:10.1146/annurev.phyto.41.052002.095505.
[55]	Bouché N, Lauressergues D, Gasciolli V, Vaucheret H. An antagonistic function for Arabidopsis DCL2 in development and a new function for DCL4 in generating viral siRNAs[J]. The EMBO Journal, 2006, 25(14):3347-3356.doi:10.1038/sj.emboj.7601217.
[56]	Ma L Q, Zhang X, Deng Z Q, Zhang P Y, Wang T, Li R, Li J Y, Cheng K, Wang J B, Ma N, Qu G Q, Zhu B Z, Fu D Q, Luo Y B, Li F, Zhu H L. Dicer-like2b suppresses the wiry leaf phenotype in tomato induced by Tobacco mosaic virus[J]. The Plant Journal, 2023, 116(6):1737-1747.doi:10.1111/tpj.16462.
[57]	Yang Y, Zhong J, Ouyang Y D, Yao J L. The integrative expression and co-expression analysis of the AGO gene family in rice[J]. Gene, 2013, 528(2):221-235.doi:10.1016/j.gene.2013.07.002. pmid: 23872535
[58]	Zhang X M, Segers G C, Sun Q H, Deng F Y, Nuss D L. Characterization of hypovirus-derived small RNAs generated in the chestnut blight fungus by an inducible DCL-2-dependent pathway[J]. Journal of Virology, 2008, 82(6):2613-2619.doi:10.1128/JVI.02324-07. pmid: 18199652
[59]	Wu J G, Yang Z R, Wang Y, Zheng L J, Ye R Q, Ji Y H, Zhao S S, Ji S Y, Liu R F, Xu L, Zheng H, Zhou Y J, Zhang X, Cao X F, Xie L H, Wu Z J, Qi Y J, Li Y. Viral-inducible Argonaute18 confers broad-spectrum virus resistance in rice by sequestering a host microRNA[J]. eLife, 2015,4:e05733.doi:10.7554/eLife.05733.
[60]	Yang Z R, Huang Y, Yang J L, Yao S Z, Zhao K, Wang D H, Qin Q Q, Bian Z, Li Y, Lan Y, Zhou T, Wang H, Liu C, Wang W M, Qi Y J, Xu Z H, Li Y. Jasmonate signaling enhances RNA silencing and antiviral defense in rice[J]. Cell Host & Microbe, 2020, 28(1):89-103.e8.doi:10.1016/j.chom.2020.05.001.
[61]	Liu M, Wu H J, Hong N, Kang B S, Peng B, Liu L M, Gu Q S. Argonaute 1 and 5 proteins play crucial roles in the defence against Cucumber green mottle mosaic virus in watermelon[J]. Molecular Plant Pathology, 2023, 24(8):961-972.doi:10.1111/mpp.13344.
[62]	Karran R A, Sanfaçon H. Tomato ringspot virus coat protein binds to ARGONAUTE 1 and suppresses the translation repression of a reporter gene[J]. Molecular Plant-Microbe Interactions, 2014, 27(9):933-943.doi:10.1094/MPMI-04-14-0099-R. pmid: 24804809
[63]	Schwach F, Vaistij F E, Jones L, Baulcombe D C. An RNA-dependent RNA polymerase prevents meristem invasion by Potato virus X and is required for the activity but not the production of a systemic silencing signal[J]. Plant Physiology, 2005, 138(4):1842-1852.doi:10.1104/pp.105.063537. pmid: 16040651
[64]	Qu F, Ye X H, Hou G C, Sato S, Clemente T E, Morris T J. RDR6 has a broad-spectrum but temperature-dependent antiviral defense role in Nicotiana benthamiana[J]. Journal of Virology, 2005, 79(24):15209-15217.doi:10.1128/JVI.79.24.15209-15217.2005.
[65]	Vaistij F E, Jones L. Compromised virus-induced gene silencing in RDR6-deficient plants[J]. Plant Physiology, 2009, 149(3):1399-1407.doi:10.1104/pp.108.132688. pmid: 19129420
[66]	Wang X B, Wu Q F, Ito T, Cillo F, Li W X, Chen X M, Yu J L, Ding S W. RNAi-mediated viral immunity requires amplification of virus-derived siRNAs in Arabidopsis thaliana[J]. Proceedings of the National Academy of Sciences of the United States of America, 2010, 107(1):484-489.doi:10.1073/pnas.0904086107.
[67]	王冕. 棉花RNA依赖的RNA聚合酶6(GhRDR6)基因的分离及功能分析[D]. 泰安: 山东农业大学, 2011.doi:10.7666/d.D143614.
	Wang M. Identification and functional analysis of a RNA-dependent RNA polymerase(RDR6)gene from cotton[D]. Taian: Shandong Agricultural University,2011.
[68]	Leibman D, Kravchik M, Wolf D, Haviv S, Weissberg M, Ophir R, Paris H S, Palukaitis P, Ding S W, Gaba V, Gal-On A. Differential expression of cucumber RNA-dependent RNA polymerase 1 genes during antiviral defence and resistance[J]. Molecular Plant Pathology, 2018, 19(2):300-312.doi:10.1111/mpp.12518. pmid: 27879040
[69]	Leibman D, Wolf D, Saharan V, Zelcer A, Arazi T, Yoel S, Gaba V, Gal-On A. A high level of transgenic viral small RNA is associated with broad potyvirus resistance in cucurbits[J]. Molecular Plant-Microbe Interactions, 2011, 24(10):1220-1238.doi:10.1094/MPMI-05-11-0128. pmid: 21899438
[70]	Verlaan M G, Hutton S F, Ibrahem R M, Kormelink R, Visser R G F, Scott J W, Edwards J D, Bai Y L. The Tomato yellow leaf curl virus resistance genes Ty-1 and Ty-3 are allelic and code for DFDGD-class RNA-dependent RNA polymerases[J]. PLoS Genetics, 2013, 9(3):e1003399.doi:10.1371/journal.pgen.1003399.

引物名称 Gene name	正向引物(5'—3') Forward sequence (5'—3')
Actin	CAGCACCTTCCAGCAGATGT	AGAAGTCTTTTCCTTTCACCAAC
ShDCL1	GTTTTCCTCCCTCCTGAGCT	GCGGTCAATGCTTCCAAGAT
ShDCL2a	TGCTTCCGGAACTATGTGGT	AGCTGAGGGATCAAACCGAA
ShDCL2b	GCTCGCAAAATACCGGGATT	TGCCTCAACCACATCAGCTA
ShDCL2c	CTTCAACACTCTTGCCTGCA	CCGGTTAAAGTAGCAGTGCC
ShDCL2d	CGAAGAGCTCCTAACGTCCT	TGATGTCCACTCCAAGCCAT
ShDCL3	TGTGTGGCTAAGCAAGGAGA	GCTCTCTGCGGAAAGAATGG
ShDCL4	TTGGAAGTGCGGGTTTCTTG	GCACGCCCTCTAGACTGTAT
ShAGO1a	CGGCCTGGAAAGGGTAGTAA	TTACCAGCTGCTCCATGACA
ShAGO1b	GAAAGTACCGCATCGCCAAT	ACCCTCGACAATCTTGCAGA
ShAGO2a	TCGTCGTACAAGCCAGAAGT	TTGAACTGAATCTCGCGCTG
ShAGO2b	TCCCGGGATGCTGACAAATA	GACTCCCACTCACACCATCA
ShAGO3	ACAACCTCCCTTGAACCCAA	GCCTTCCACCACAGATTTCC
ShAGO4a	AAATGCTCTGCGTGGTCAAG	CCAGCACCGACATCAACAAA
ShAGO4b	ACAACGGTACCAATGGCAAC	CTCAGACTCTTGACCTCGCA
ShAGO4c	TTGAGTTGGAGGTGGGTGTT	TTTTGCCTTCGCCCAATCAA
ShAGO4d	TCGCCTACTCACCAACCATT	TCTTTGCCAGCTAGCTCCAT
ShAGO5	CTAAATGGCAGGCAGGTCAC	GGTGGGATCTGTTGGGAGAA
ShAGO6	GCAGAGCCAGAGAGAGTTGA	ACGGCCCTCTTTTCATCAGA
ShAGO7	TAGATGTTGTGTTGCGCGAG	TCTCGTGGAAAGCAGTCACT
ShAGO10a	AAGGCCTTGTACAGCAGCTA	TCCCAAGTTGCCCATAACCT
ShAGO10b	TTGCAGACCATTCGCCAAAA	AAGTTGATGCAAGCCCAGTG
ShAGO15	GCCAATCGTACTTCCCCAAC	TTTTCGCCTTTGTCCAGTCG
ShRDR1	TTCGGCTTGGTACCACGTTA	TGAGAACTGGCCTGTTACGT
ShRDR2	CGAGAGGCCATGGTAGAGTT	CCCAAGTCTCCAAAACCTGC
ShRDR3a	ACTTGCTGTCCCTGTGAAGA	GATTCGGCTCCACGGTTTAC
ShRDR3b	ACACGGGCCATGAACTTAGA	CGCAGAACCAGCTACTTTCC
ShRDR6a	TGCTAGGCGTGATGAACTCT	CCCTCCAACCAACCACAAAG
ShRDR6b	TCCCCAGAAAACTGCCATCT	CTGAACCTCCCCATCCAGTT

引物名称 Gene name	正向引物(5'—3') Forward sequence (5'—3')
Actin	CAGCACCTTCCAGCAGATGT	AGAAGTCTTTTCCTTTCACCAAC
ShDCL1	GTTTTCCTCCCTCCTGAGCT	GCGGTCAATGCTTCCAAGAT
ShDCL2a	TGCTTCCGGAACTATGTGGT	AGCTGAGGGATCAAACCGAA
ShDCL2b	GCTCGCAAAATACCGGGATT	TGCCTCAACCACATCAGCTA
ShDCL2c	CTTCAACACTCTTGCCTGCA	CCGGTTAAAGTAGCAGTGCC
ShDCL2d	CGAAGAGCTCCTAACGTCCT	TGATGTCCACTCCAAGCCAT
ShDCL3	TGTGTGGCTAAGCAAGGAGA	GCTCTCTGCGGAAAGAATGG
ShDCL4	TTGGAAGTGCGGGTTTCTTG	GCACGCCCTCTAGACTGTAT
ShAGO1a	CGGCCTGGAAAGGGTAGTAA	TTACCAGCTGCTCCATGACA
ShAGO1b	GAAAGTACCGCATCGCCAAT	ACCCTCGACAATCTTGCAGA
ShAGO2a	TCGTCGTACAAGCCAGAAGT	TTGAACTGAATCTCGCGCTG
ShAGO2b	TCCCGGGATGCTGACAAATA	GACTCCCACTCACACCATCA
ShAGO3	ACAACCTCCCTTGAACCCAA	GCCTTCCACCACAGATTTCC
ShAGO4a	AAATGCTCTGCGTGGTCAAG	CCAGCACCGACATCAACAAA
ShAGO4b	ACAACGGTACCAATGGCAAC	CTCAGACTCTTGACCTCGCA
ShAGO4c	TTGAGTTGGAGGTGGGTGTT	TTTTGCCTTCGCCCAATCAA
ShAGO4d	TCGCCTACTCACCAACCATT	TCTTTGCCAGCTAGCTCCAT
ShAGO5	CTAAATGGCAGGCAGGTCAC	GGTGGGATCTGTTGGGAGAA
ShAGO6	GCAGAGCCAGAGAGAGTTGA	ACGGCCCTCTTTTCATCAGA
ShAGO7	TAGATGTTGTGTTGCGCGAG	TCTCGTGGAAAGCAGTCACT
ShAGO10a	AAGGCCTTGTACAGCAGCTA	TCCCAAGTTGCCCATAACCT
ShAGO10b	TTGCAGACCATTCGCCAAAA	AAGTTGATGCAAGCCCAGTG
ShAGO15	GCCAATCGTACTTCCCCAAC	TTTTCGCCTTTGTCCAGTCG
ShRDR1	TTCGGCTTGGTACCACGTTA	TGAGAACTGGCCTGTTACGT
ShRDR2	CGAGAGGCCATGGTAGAGTT	CCCAAGTCTCCAAAACCTGC
ShRDR3a	ACTTGCTGTCCCTGTGAAGA	GATTCGGCTCCACGGTTTAC
ShRDR3b	ACACGGGCCATGAACTTAGA	CGCAGAACCAGCTACTTTCC
ShRDR6a	TGCTAGGCGTGATGAACTCT	CCCTCCAACCAACCACAAAG
ShRDR6b	TCCCCAGAAAACTGCCATCT	CTGAACCTCCCCATCCAGTT

序号 Number	基因名称 Gene name	序列登录号 Gene ID	位置/bp Genomic location	CDS长度/ bp CDS length	氨基酸长度/个 Amino acid length	等电点 PI	分子质量/ku Molecular weight	亚细胞定位 Subcellular localization	同源性最高的番茄基因编号 Tomato gene number with the highest homology
Dicer-like(DCL)
1	ShDCL1	Shab10g000160.1	chr10:117674—131266	5 043	1 680	5.69	188.69	1	Solyc10g005130
2	ShDCL2a	Shab06g007210.1	chr6:31381067—31393838	4 209	1 402	6.53	158.02	1	Solyc06g048960
3	ShDCL2b	Shab11g003360.1	chr11:2797006—2801926	3 531	1 176	7.45	132.99	1	Solyc11g008540
4	ShDCL2c	Shab11g003340.1	chr11:2779197—2786011	1 083	360	4.81	39.51	1	Solyc11g008520
5	ShDCL2d	Shab11g003370.1	chr11:2805943—2811457	3 426	1 141	7.75	129.65	1	Solyc11g008530
6	ShDCL3	Shab08g011760.1	chr8:52079657—52106758	3 843	1 280	7.66	143.50	1	Solyc08g067210
7	ShDCL4	Shab07g000040.1	chr7:61116—94001	4 862	1 620	6.47	182.25	1	Solyc07g005030
Argonaute(AGO)
1	ShAGO1a	Shab06g018510.1	chr6:46211483—46220383	3 165	1 054	9.48	116.70	1	Solyc06g072300
2	ShAGO1b	Shab03g017920.1	chr3:56608587—56615954	3 459	1 152	9.46	126.91	1	Solyc03g098280
3	ShAGO2a	Shab02g010500.1	chr2:41010367—41017103	3 120	1 039	9.39	115.62	1	Solyc02g069260
4	ShAGO2b	Shab02g010510.1	chr2:41030311—41034222	2 946	981	9.02	110.74	1	Solyc02g069270
5	ShAGO3	Shab02g010520.1	chr2:41036447—41040263	3 000	999	8.90	112.47	1	Solyc02g069280
6	ShAGO4a	Shab01g003450.1	chr1:3233010—3238637	2 604	867	9.03	97.20	1,2	Solyc01g008960
7	ShAGO4b	Shab06g019700.1	chr6:47008379—47013982	2 769	922	9.33	103.56	1	Solyc06g073540
8	ShAGO4c	Shab06g019690.1	chr6:46997111—47003903	2 748	915	9.31	102.46	3	Solyc06g073530
9	ShAGO4d	Shab01g021530.1	chr1:86969262—86973908	2 646	881	9.23	98.86	1	Solyc01g096750
10	ShAGO5	Shab06g020800.1	chr6:47999599—48006297	2 775	924	9.61	102.99	1	Solyc06g074730
11	ShAGO6	Shab07g013570.1	chr7:62215729—62224152	2 574	857	8.75	96.62	1,2,3	Solyc07g049500
12	ShAGO7	Shab01g005290.1	chr1:7642775—7651741	2 934	977	9.31	111.06	1,2	Solyc01g010970
13	ShAGO10a	Shab09g017290.2	chr73523970—73531554	3 045	1 014	9.23	114.50	1	Solyc09g082830
14	ShAGO10b	Shab12g001730.1	chr12:1289252—1303393	2 817	938	9.31	106.26	1,2	Solyc12g006790
15	ShAGO15	Shab03g020040.1	chr3:58631540—58637276	2 808	935	9.55	106.33	2,3	Solyc03g111760
RNA-dependent RNA polymerase(RDR)
1	ShRDR1	Shab05g002220.1	chr5:2080655—2087989	3 204	1 067	8.56	121.10	3	Solyc05g007510
2	ShRDR2	Shab03g022350.1	chr3:60533575—60539371	3 360	1 119	6.64	127.44	1	Solyc03g114140
3	ShRDR3a	Shab12g002370.1	chr12:1956348—1968345	3 156	1 051	8.06	121.03	3,4	Solyc12g008410
4	ShRDR3b	Shab06g008130.1	chr6:34277469—34305043	3 042	1 013	7.80	115.50	3	Solyc06g051170
5	ShRDR6a	Shab04g006050	chr4:5359143—5366807	3 594	1 197	6.47	136.17	3	Solyc04g014870
6	ShRDR6b	Shab08g014840.1	chr8:56984431—56986296	1 866	621	8.76	70.50	3	Solyc08g075820

序号 Number	基因名称 Gene name	序列登录号 Gene ID	位置/bp Genomic location	CDS长度/ bp CDS length	氨基酸长度/个 Amino acid length	等电点 PI	分子质量/ku Molecular weight	亚细胞定位 Subcellular localization	同源性最高的番茄基因编号 Tomato gene number with the highest homology
Dicer-like(DCL)
1	ShDCL1	Shab10g000160.1	chr10:117674—131266	5 043	1 680	5.69	188.69	1	Solyc10g005130
2	ShDCL2a	Shab06g007210.1	chr6:31381067—31393838	4 209	1 402	6.53	158.02	1	Solyc06g048960
3	ShDCL2b	Shab11g003360.1	chr11:2797006—2801926	3 531	1 176	7.45	132.99	1	Solyc11g008540
4	ShDCL2c	Shab11g003340.1	chr11:2779197—2786011	1 083	360	4.81	39.51	1	Solyc11g008520
5	ShDCL2d	Shab11g003370.1	chr11:2805943—2811457	3 426	1 141	7.75	129.65	1	Solyc11g008530
6	ShDCL3	Shab08g011760.1	chr8:52079657—52106758	3 843	1 280	7.66	143.50	1	Solyc08g067210
7	ShDCL4	Shab07g000040.1	chr7:61116—94001	4 862	1 620	6.47	182.25	1	Solyc07g005030
Argonaute(AGO)
1	ShAGO1a	Shab06g018510.1	chr6:46211483—46220383	3 165	1 054	9.48	116.70	1	Solyc06g072300
2	ShAGO1b	Shab03g017920.1	chr3:56608587—56615954	3 459	1 152	9.46	126.91	1	Solyc03g098280
3	ShAGO2a	Shab02g010500.1	chr2:41010367—41017103	3 120	1 039	9.39	115.62	1	Solyc02g069260
4	ShAGO2b	Shab02g010510.1	chr2:41030311—41034222	2 946	981	9.02	110.74	1	Solyc02g069270
5	ShAGO3	Shab02g010520.1	chr2:41036447—41040263	3 000	999	8.90	112.47	1	Solyc02g069280
6	ShAGO4a	Shab01g003450.1	chr1:3233010—3238637	2 604	867	9.03	97.20	1,2	Solyc01g008960
7	ShAGO4b	Shab06g019700.1	chr6:47008379—47013982	2 769	922	9.33	103.56	1	Solyc06g073540
8	ShAGO4c	Shab06g019690.1	chr6:46997111—47003903	2 748	915	9.31	102.46	3	Solyc06g073530
9	ShAGO4d	Shab01g021530.1	chr1:86969262—86973908	2 646	881	9.23	98.86	1	Solyc01g096750
10	ShAGO5	Shab06g020800.1	chr6:47999599—48006297	2 775	924	9.61	102.99	1	Solyc06g074730
11	ShAGO6	Shab07g013570.1	chr7:62215729—62224152	2 574	857	8.75	96.62	1,2,3	Solyc07g049500
12	ShAGO7	Shab01g005290.1	chr1:7642775—7651741	2 934	977	9.31	111.06	1,2	Solyc01g010970
13	ShAGO10a	Shab09g017290.2	chr73523970—73531554	3 045	1 014	9.23	114.50	1	Solyc09g082830
14	ShAGO10b	Shab12g001730.1	chr12:1289252—1303393	2 817	938	9.31	106.26	1,2	Solyc12g006790
15	ShAGO15	Shab03g020040.1	chr3:58631540—58637276	2 808	935	9.55	106.33	2,3	Solyc03g111760
RNA-dependent RNA polymerase(RDR)
1	ShRDR1	Shab05g002220.1	chr5:2080655—2087989	3 204	1 067	8.56	121.10	3	Solyc05g007510
2	ShRDR2	Shab03g022350.1	chr3:60533575—60539371	3 360	1 119	6.64	127.44	1	Solyc03g114140
3	ShRDR3a	Shab12g002370.1	chr12:1956348—1968345	3 156	1 051	8.06	121.03	3,4	Solyc12g008410
4	ShRDR3b	Shab06g008130.1	chr6:34277469—34305043	3 042	1 013	7.80	115.50	3	Solyc06g051170
5	ShRDR6a	Shab04g006050	chr4:5359143—5366807	3 594	1 197	6.47	136.17	3	Solyc04g014870
6	ShRDR6b	Shab08g014840.1	chr8:56984431—56986296	1 866	621	8.76	70.50	3	Solyc08g075820

多毛番茄 S.habrochaites		番茄 S.lycopersicum		拟南芥 Arabidopsis
AGO	Motifs	AGO	Motifs	AGO	Motifs
ShAGO2a	DDD/H	SlAGO2a	DDD/H	AtAGO2	DDD/H
ShAGO2b	DDD/H	ShAGO2b	DDD/H	AtAGO3	DDD/H
ShAGO3	DDD/S	ShAGO3	DDD/S	AtAGO4	DDH/S
ShAGO4a	DDH/P	ShAGO4a	DDH/P	AtAGO6	DDH/P
ShAGO4b	DDH/P	ShAGO4b	DDH/P	AtAGO8	DDH/P
ShAGO4c	DDH/P	ShAGO4c	DDH/P	AtAGO9	DDH/R
ShAGO4d	DDH/P	ShAGO4d	DDH/P
ShAGO5	DDH/P	ShAGO6	DDH/P
ShAGO6	DDH/P	ShAGO15	GQR/P
ShAGO15	GQR/P

选择文件类型/文献管理软件名称

选择包含的内容
